INTRODUCTION
Optima User Manual
1
INTRODUCTION
Welcome
Congratulations on purchasing this Data I/O programmer. You are about to discover
the ease of use and flexibility that make Data I/O programmers the leading choice for
professional users.
This Optima User Manual will lead you through the process of setting up and running
any of these engineering and production products programmers in the Optima family:
Singlesyte Multisyte
Plus 48 Dual
Optima Quad
Optima Light Octal
Whether Singlesyte or Multisyte, all Optima family programmers are controlled with
the same simple, intuitive screen controls of the Optima Windows software.
All Optima family programmers (with the exception of the Plus 48) will accept any of
the interchangeable TOP Socket Modules or Production Adapters. A few of the TOP
Socket Modules and Production Adapters are listed here:
TOP Socket Modules
TOP84PLC TOP3PLC
TOP44PLC TOP68PLC
TOP48DIP TOP432DIP
FlashTOP
Production Adapters
Universal Adapter Base
Universal SOIC Production Adapter
Additional Production Adapters to
support TSOPs, PBGAs, QFPs and
others.
INTRODUCTION
Optima User Manual
2
To use this universal hardware and software you simply connect the programmer and
TOP to your computer, install the software, and you’re ready to begin programming.
Your Windows dialog box will graphically display which programmer and TOP you
are using.
Note: Most of the software commands described in the Optima
User Manual apply to all programmers in the Optima
family. If a command or operation applies to only one of the
programmers, a special Note will alert you. If there is no
special Note, then the same command works with all
programmers.
INTRODUCTION
Optima User Manual
3
System Overview
As a peripheral to your PC, the programmer utilizes the RAM, CPU, and disk drives
in your computer for user interface and data exchange. The programmer comes with
its own power supply (internal or external) and timing circuits for accurate generation
of programming signals.
Standard Features
Standard features of the Optima programmers include:
High Pin Count: Up to 84 pins. Standard 48 pin (300/600 mil) DIP socket
supports devices from 8-48 pins. Additional pin drivers, if required, reside in
the individual TOPs.
Universal ASIC Pin Drivers: These provide precise digital and analog
signals on every pin. Controlled rise times and advanced noise suppression
circuitry assure high quality, reliable programming.
Quick Response: Single keystroke operation and instantaneous file load
times make Optima both quick to learn and easy to use.
Device Support: PROMs, EPROMs, EEPROMs, PLDs, EPLDs, EEPLDs,
GALs, FPLAs, IFLs, MCUs, Flash and more in 3 and 5 volt technologies, and
in various package types.
PC Peripheral: Optima uses the computer’s existing RAM, Disk, Keyboard
and Display to provide maximum price/performance.
Relay Power/Ground: Optimal noise-free device power for highest yields.
Fast Clock: Fast rise times (3 ns) allow reliable vector testing.
State Machine Waveform Generation: Internal crystal controlled state-
machine ensures accurate programming waveforms not dependent on PC
timing.
Full Screen Menus: These make the Optima easy to learn and operate.
Customize User Interface Option: All input commands can be executed
from a batch file, or via a network or multitasking Windows environment, on
a local or remote PC.
