Chapter 5 Specifications
Contents
1. Auto loading feeder specifications 5-1
1.1 Basic specification 5-1
1.2 Feeder type (model)/available component 5-1
1.3 Tape loading/Tape auto-replace durations 5-2
2. Component tape reference specifications 5-3
2.1 Limitation of meandering 5-3
2.2 Tensile testing 5-3
2.3 Top of component tape 5-4
2.4 End of component tape 5-4
2.5 Component position in pocket 5-4
2.6 Tensile strengths of carrier tape/cover tape 5-5
2.7 Size of 8mm tape reel 5-5
1. Auto loading feeder specifications
5-1
Chapter 5 Specifications
1. Auto loading feeder specifications
1.1 Basic specification
Item Description Remark
External dimension (mm) L 548 × W 11.5 × H 280
Weight (kg) 1.5
Compatible models
YSM20, YSM20W, YSM20R, YSM40R, YRM20
YSM10, YS24, YS12, YS12P/F YSM40,
YS24X, YS100, YS88 , YRM20 and more
Following are incompatible:
-Without tape cutter
-YS100FNC head model
Available carrier tape
Material: Paper
Width: 8 mm
Maximum thickness: 1 mm
Limitation applies.
Feed pitch 2 mm / 4mm
Available reel specification
Width: 14.4 mm or less
Diameter: 382 mm or less
13.0 mm or less when using preset
holder
8 mm converted loading witdh 12 mm pitch: 1
Shortest length of component tape to
load
400 mm or longer
Longest length of tape without
component from end available for auto
supply of spare components
300 mm or shorter
600 mm or shorter when using
IT-Option
Feeder type (available component)
2S (0603/1005), S(1005), M(1608),
L(2012), LL(3216))
Size labels on tape guide and
operation panel must be same.
n
NOTE
See the product specification for detail about compatible models.
1.2 Feeder type (model)/available component
Model Tape width Feed pitch
Tape
material
Standard
Reel Dia.× Width
External
dimension (mm)
Cover tape
Seal witdh
(mm)
Available
component
size
2S 8 mm 2 mm Paper
∅
180×14.4 mm
0.4 < X
≤
1.0
0.2 < Y
≤
0.5
1.4 or more 0603/1005
S 8 mm 2 mm Paper
0.6 < X
≤
1.0
0.3 < Y
≤
0.85
1.4 or more 1005
M 8 mm 2 mm / 4 mm Paper
1.0 < X
≤
1.6
0.3 < Y
≤
1.6
2.1or more 1680
L 8 mm 2 mm / 4 mm Paper
1.6 < X
≤
2.0
0.3 < Y
≤
2.0
2.6 or more 2012
LL 8 mm 2 mm / 4 mm Paper
2.0 < X
≤
3.2
0.3 < Y
≤
2.5
3.8 or more 3216
n
NOTE
• Splicing tape is unavailable.
• Using splicing tape may result in pickup error.
• Splicing position cannot be detected.
• The 0603 (0201) size of 2S feeder supports only magnetic components.
1. Auto loading feeder specifications
5-2
Chapter 5 Specifications
1.3 Tape loading/Tape auto-replace durations
No Item Duration Description
1 Tape loading duration Approx. 5 sec.
Duration from starting component tape loading after setting top of
component tape to specified position on feeder to completing component
tape feeding to pickup position.
2 Tape auto-replace duration Approx. 8 sec.
Duration to replace component tape in operation (1st tape) that runs out
of component with component tape to be added (2nd tape) automatically.
n
NOTE
• Durations above vary depending on the component tape size or feed pitch.
• Tape auto-replace duration includes discharging time of 1st tape that runs out of component.
