The instruction manual of this machine is written for those who operate this machine. Please read this manual carefully for correct operations and pay special attention to safety precautions. After reading through this m…
General Contents
Chapter 5 Specifications
1. Auto loading feeder specifications 5-1
1.1 Basic specification 5-1
1.2 Feeder type (model)/available component 5-1
1.3 Tape loading/Tape auto-replace durations 5-2
2. Component tape reference specifications 5-3
2.1 Limitation of meandering 5-3
2.2 Tensile testing 5-3
2.3 Top of component tape 5-4
2.4 End of component tape 5-4
2.5 Component position in pocket 5-4
2.6 Tensile strengths of carrier tape/cover tape 5-5
2.7 Size of 8mm tape reel 5-5
The instruction manual of this machine is written for those who operate
this machine.
Please read this manual carefully for correct operations and pay special
attention to safety precautions.
After reading through this manual, please use this manual as an
occasional reference and keep it within reach.
Introduction
Contents
1. About this manual S-1
1.1 Contens of each chapter S-1
2. Safety S-2
2.1 Common precautions S-2
2.2 Safety message S-3
2.3 Keeping body and objects away from moving parts S-4
1. About this manual
S-1
Introduction
1. About this manual
The instruction manual of this machine is written for those who operate this machine. Please read this
manual carefully for correct operations and pay special attention to safety precautions.
After reading through this manual, please use this manual as an occasional reference and keep it within
reach.
►
About the contents in this manual
The parts (Part Nos.) for maintenance in this manual are at the time of issuing this manual. The Part
Nos. may be changed without prior notice. Make sure to verify the latest Part Nos. with your sales
representative before ordering.
1.1 Contens of each chapter
This manual is composed of the following chapters.
►
Chapter 1 Overview
Describes about the names of each parts and their function of Auto Loading Feeder.
Also describes about the available component sizes and the jigs for tape component preparation, and
the available component tape and its specification.
►
Chapter 2 Handling component tape
Describes the cutting position, cutting procedure and folding the top of component tape as the
preparation for attaching tape component to this equipment.
Also describes about the tape attaching/detaching procedure of Auto Loading Feeder.
►
Chapter 3 Setting up
• Describes about the preparation before operation, as such the software setting and maximizing to
use Auto Loading Feeder.
• Describes about the setting up of component tape.
• Describes about the preset holder/Feeder exchange carriages, and the operation panel and its
operating procedure.
• Also describes the popular troubleshooting.
►
Chapter 4 maintenance, repair and replacement
Describes about the maintenance sections/Replaceable parts of Auto Loading Feeder, and the part
replacement procedure.
►
Chapter 5 Specifications
Describes about Auto Loading Feeder specification and the component tape specifications.
w
WARNING
MAKE SURE TO READ "2. SAFETY" DESCRIBED ON THE NEXT PAGE BEFORE THE MAINTENANCE OPERATION.
