Specications of Model MR8740T
Maximum recording
length
Real-time sampling For the xed recording length setting:
When 27 modules are used
2 M (with Model U8991 installed)
5 M (with Model U8975, U8977, U8978, or MR8990
installed)
10 M (54 channels, in points*)
When 16 modules are used
5 M (with Model U8991 installed)
10 M (with Model U8975, U8977, U8978, or MR8990
installed)
20 M (32 channels, in points*)
When 8 modules are used
10 M (with Model U8991 installed)
20 M (with Model U8975, U8977, U8978, or MR8990
installed)
50 M (16 channels, in points*)
When 4 modules are used
20 M (with Model U8991 installed)
50 M (with Model U8975, U8977, U8978, or MR8990
installed)
100 M (8 channels, in points*)
For freely-specied recording length setting:
When 27 modules are used
4194300 (with Model U8991 installed)
8388600 (with Model U8975, U8977, U8978, or
MR8990 installed)
16777200 (54 channels, in points*)
When 16 modules are used
8388600 (with Model U8991 installed)
16777200 (with Model U8975, U8977, U8978, or
MR8990 installed)
33554400 (32 channels, in points*)
When 8 modules are used
16777200 (with Model U8991 installed)
33554400 (with Model U8975, U8977, U8978, or
MR8990 installed)
67108800 (16 channels, in points*)
When 4 modules are used
33554400 (with Model U8991 installed)
67108800 (with Model U8975, U8977, U8978, or
MR8990 installed)
134217600 (8 channels, in points*)
* Can be set in 100 points increments
For the real-time save
setting
The maximum recording length is dened depending on a
free space of a destination, le systems, and the number of
measuring channels.
Repeat
measurements
Single, repeat, count
Scaling Ratio and offset, 2-point, model name, output rate, decibel, rating
Model name: The scaling is automatically specied by selecting a connected model.
The combination use of auto-recognition and auto-scaling is supported when a current
measuring module is used.
Comment Title comment, channel comment
The instrument displays both of channel numbers and channel comments on the setting
and waveform screens.
Help The instrument displays the instruction manuals.
97
Specications of Model MR8740T
File
1. Data saving
Destination to save
SSD:
USB ash drive:
FTP transfer:
Email transmission:
Built-in SSD (storage capacity: 480 GB)
Model Z4006 USB Drive (16 GB)
Computer connected via LAN
The instrument sends email messages with a le attached to
user-dened destination.
File format FAT, FAT32, NTFS, exFAT
File name Alphanumeric le names can be entered.
Handling of same-
name les
Prexes a sequential number to the le name and saves the le. (For FTP transmission,
sufxes data and time)
Auto-save On/Off
* Automatically saves the acquired data with a recording length after each measurement.
* No setting les are supported.
* Not available when the real-time save is selected.
Real-time save On/Off
* Directly saves waveform data (binary) acquired during measurement to the save
destination.
* Auto-save setting is unavailable.
Older-le overwriting If a free space of a destination is insufcient, the existing les are overwritten beginning
with the oldest.
(Available with the auto-save setting)
Saving format Setting data:
Measured data:
Index:
Screenshot:
Numerical calculation result:
Startup:
.SET
Binary (.MEM, .FLT), text (.CSV)
Division save (.IDX)
.BMP, .PNG, .JPG
.CSV
STARTUP.SET
Channels to be
saved
When the saving format is set to the measured data, the channels to be saved can be
selected between all channels and displayed channels.
Data decimation
save
With the saving format set to measured data (in text format), data is decimated by retaining
one out of the specied decimation number (2 to 1000) and the remaining data is saved.
File division
Saving format Division content
Binary format Off, every 16 MB, every 32 MB, every 64 MB
Text format Off, every 60,000 data points, every 1,000,000 data points
Numerical
calculation result
Off, by calculation number
File designation New le or existing le
(Enabled when the saving format is set to the numerical calculation result)
(Before starting a measurement, select whether a new le is created or data is appended
to the existing le)
Save operation
Quick save: The save icon is used to save data based on a preset destination, le name,
and saving setting.
Saving range: All or a specied segment range can be selected.
(Available only for saving data started by click the save icon)
5
Specications
98
Specications of Model MR8740T
2. Data loading
Drive from which
data is loaded
SSD:
USB ash drive:
Built-in SSD (storage capacity: 480 GB)
Model Z4006 USB Drive (16 GB)
Loadable data
formats
Setting data (.SET)
Measured data: Binary format (.MEM)
Index: Division save (.IDX)
Startup: STARTUP.SET
Performing calculation
1. Numerical calculation
Maximum number of
calculations
(108 items) × (the number of measuring channels)
Calculation range All or a specied segment
Statistical functions Start, average, maximum, minimum
Calculation items P-P, maximum, minimum, high level, low level, average, RMS, standard deviation, rise
time*, fall time*, frequency*, period*, duty ratio*, pulse count, area, X-Y area, time lag*,
phase contrast*, time to maximum, time to minimum, time to level, level at time, pulse
width*, four arithmetic operations, intermediate, amplitude, accumulation, burst width*,
angle of XY waveform, overshoot, undershoot, +Width*, −Width*
*: Statistical functions (start, average, maximum, minimum) available
Numerical judgment
Target waveform: Analog, logic, and waveform calculation channels
Judge setting: On/Off
Stopping
condition:
PASS, FAIL, PASS & FAIL
2. Waveform calculation
Maximum number of
calculations
16 expressions
Calculation range All or a specied segment
Maximum recording
length
2,000,000 points
Standard operators +, −, ×, ÷
Calculation items Absolute value, square root, cubic root, logarithm, exponent, sine, arc sine, cosine, arc
cosine, tangent, arc tangent, derivative, 2nd-order derivative, integral, 2nd-order integral,
moving average, slide, PLCS
3. Memory division
Maximum division
number
1024 blocks
Block search The instrument can search data stored in divided memory blocks.
Representation Displays blocks specied.
