76
Saving Data Consisting of Items Selected
3.6 Saving Data Consisting of Items Selected
Clicking the save icon allows you to select any of the following items and save them:
• Waveform data
• Screenshot
• Numerical calculation result
• Setting
Refer to “4 Saving/Loading Data and Managing Files” of the Instruction Manual.
1
3
4
5
6
2
7
1
Click the save icon.
2
Click the [Media] box, and then choose a destination to save from the list.
SSD/HDD
Saves data on the built-in SSD.
USB Memory Saves data on the USB ash drive.
E-mail
transmission
Sends emails with waveform data attached to computers in the network or to a remote
computer.
Refer to “11.4 Sending E-mails” of the Instruction Manual.
FTP transfer Sends waveform data to a computer connected to a network.
Refer to “11.3 Sending Data to a Computer With the FTP Client Function” of the
Instruction Manual.
3
Enter the le name in the [File name] box.
Number of characters for a le name: Up to 100 characters
The maximum length of a le name that includes its path: Up to 255 characters
Some characters or symbols are not accepted due to the le system restrictions.
77
Saving Data Consisting of Items Selected
4
Click the [Type] box, and then choose a save format of waveform data or save target from
the list.
Waveform
(Binary)
Saves waveform data in binary format. Choose this option to reload the waveforms into
the instrument.
Waveform (Text) Saves waveform data in text format. Choose this option to load the waveform data into
a computer.
The instrument cannot read this type of les.
Waveform (Float) Saves waveform data in binary format (32-bit oating point).
Choose this option to load the waveform data into MATLAB. The instrument cannot
read this type of les.
Screen image Saves image data on the screen in BMP, PNG or JPEG format.
You can display the data saved on a computer with image viewing software.
Calc. Result Saves numerical calculation results.
Setting Saves the present measurement conditions.
When [Type] is set to [Waveform (Binary)] or [Waveform (Text)]
5
Tap the [Channel] box, and then choose an option for channels to be saved.
All Saves measured data of all channels.
The instrument also saves data acquired across channels with the waveform display
set to [Off].
Display
Saves the data acquired across the channels of all sheets with the waveform display
preferences set to [On].
6
Click the [Range] box, and then choose an option for save range from the list.
All
Saves all data written in the memory.
A_B Saves the data in the section between trace cursors [A] and [B].
C_D Saves the data in the section between trace cursors [C] and [D].
7
Click [Execute].
3
Measurement Method
78
Measuring Signals With the Auto-range Setting
3.7 Measuring Signals With the Auto-range Setting
The auto-range function is available only for signals inputted to analog measuring modules.
1
Input signals to an analog measuring module.
2
Click [Auto range] on the waveform screen.
3
Click [Execute].
The instrument species the sampling rate, measurement range, and zero position for each input
waveform automatically and starts a measurement.
The sampling rate is specied according to the lowest numbered channel of the channels with
[Display] set to [On]. In addition, it is automatically specied so that waveforms have a length of
between 1 cycle and 2.5 cycles while 2500 points are recorded.
The auto-range function changes the following items:
Module conditions (for all channels)
Range (f.s.)
Automatically specied value
Zero position
L.P.F Off
Input coupling DC
Triggering condition (for one channel only)
Selecting the trigger logical
operation (AND or OR operation)
among trigger sources
OR
Pre-trigger 20%
Internal trigger Detects trigger levels beginning from the channel lowest-numbered
among the channels with the [Display] button set to [On].
Trigger type Level trigger
(Slope:
, Level: Automatically specied value, Filter: 10 samples)
Measurement conditions
Sampling rate Automatically set value
Points 2.5 k
Mode Repeat
