89
Specications of Model MR8740T
(2) USB interface
Standards USB 3.0 compliant ×4, USB 2.0 compliant ×4
Number of ports Front side: 2 (USB 2.0)
Rear side: 6 (USB 3.0 ×4, USB 2.0 ×2)
Host Connector: Series-A receptacle
Peripheral devices: keyboard, mouse, USB ash drive
(3) Monitor output
Output format
VGA Resolution: 2560 × 1600 dots (maximum)
HDMI Resolution: 3840 × 2160 dots (maximum)
DisplayPort Resolution: 4096 × 2304 dots (maximum)
A resolution of 1920 × 1080 dots or more is recommended.
(4) Others
Incompatible
interface
Interface
Audio (Line-in/out, Mic-in)
RS-232C
PS2 (keyboard, mouse)
5
Specications
90
Specications of Model MR8740T
5. External control terminals
Terminal block Push-button type
External input
Maximum input
voltage
10 V DC
Input voltage High level: between 2.5 V and 10 V
Low level: between 0 V and 0.8 V
Acceptable pulse
width
High-level period: 50 ms or longer
Low-level period: 50 ms or longer
Pulse interval 200 ms or more
Number of terminals 2
Functions START, STOP, START/STOP, SAVE, ABORT, EVENT
External output
Output format Open-drain output (equipped with a 5-volt voltage output, active-
low)
Output voltage High level: between 4.0 V and 5.0 V
Low level: between 0 V and 0.5 V
Maximum input
voltage
50 V DC, 50 mA, 200 mW
Number of terminals 2
Functions Judgment (pass), judgment (fail), occurrence of an error, busy,
waiting for a trigger
External trigger
Maximum input
voltage
10 V DC
External trigger lter On/Off
Acceptable pulse
width
When the external trigger lter is off
High-level period: 1 ms or longer
Low-level period: 2 µs or longer
When the external trigger lter is on
High-level period: 2.5 ms or longer
Low-level period: 2.5 ms or longer
Functions The edge to be used can be chosen between rising and falling.
Rising: Triggered when a pulse rises from the low level
(between 0 V and 0.8 V) to the high level (between 2.5 V
and 10 V).
Falling: Triggered when a pulse falls from the high level
(between 2.5 V and 10 V) to the low level (between 0 V
and 0.8 V), or when the terminals are connected with
each other.
Trigger output
Output format Open-drain output (equipped with a 5-volt voltage output, active-
low)
Output voltage High level: between 4.0 V and 5.0 V
Low level: between 0 V and 0.5 V
Maximum input
voltage
50 V DC, 50 mA, 200 mW
Output pulse width The pulse width to be used can be chosen between level and
pulse.
Level: [(sampling interval) × (number of data sets after trigger)] or
more
Pulse: 2 ms ±1 ms
91
Specications of Model MR8740T
External sampling
input
Maximum input
voltage
10 V DC
Input voltage High level: between 2.5 V and 10 V, low level: between 0 V and
0.8 V
Acceptable pulse
width
High-level period: 50 ns or longer, low-level period: 50 ns or longer
Maximum input
frequency
10 MHz
Functions External sampling clock input
The edge to be used can be chosen between rising and falling.
