150
Message
Warning messages
The list of warning messages is as follows. Check the solution.
No. Message Solution Reference page
10 Please insert media. Insert a USB ash drive.
“2.5 Preparing Storage Devices
(Recording Media)” (p. 57)
13 Disk full.
The instrument cannot save any
les because of insufcient free
space on the storage device.
Delete unnecessary les to free
up enough space or use a new
storage device.
“2.5 Preparing Storage Devices
(Recording Media)” (p. 57)
“4.4 Managing Files” of
Instruction Manual
14 Cannot load this le.
The chosen le cannot be
loaded.
“4.3 Loading Data” of Instruction
Manual
15 Unable to access le.
Check that the storage device
is properly inserted.
“2.5 Preparing Storage Devices
(Recording Media)” (p. 57)
22 No waveform data to save.
Perform another measurement
or load a le.
“4.3 Loading Data” of Instruction
Manual
25 This device cannot be removed.
The instrument is accessing the
device. Eject the device when
the DIAG LED lights up in other
than green.
“1.2 Name and Function of
Each Part” (p. 22)
30 Auto-ranging failed. Check the input signals.
“3.7 Measuring Signals With the
Auto-range Setting” (p. 78)
31 Invalid section cursor position.
Section cursors are placed at
improper positions (outside the
waveform range). Check the
section cursor positions.
“2.3 Scrolling Through
Waveforms” of Instruction
Manual
44 No event mark. Put an event mark.
“12.1 External Input and Output”
of Instruction Manual
45 Out of range. – –
60 No waveform data.
Acquire Measures waveform
data.
–
70
Voltage sag triggering is
disabled (valid time base range:
2 kS/s to 100 MS/s).
The voltage drop trigger
setting can be used only in the
sampling rate range from 2 kS/s
to 20 MS/s.
“5.6 Triggering the Instrument
Using Analog Signals” of
Instruction Manual
74 Auto balance failed.
Make sure that the strain gauge
transducer is not loaded, and
it is correctly connected to a
measuring target.
“Strain gauge transducer”
(p. 41)
78 Recording length is too long.
To perform waveform
calculation, set the recording
length at 2 M points or less.
“8 Waveform Calculation
Function” of Instruction Manual
83 No channel selected for use.
Set the [Use] buttons on one or
more of the channels to [On].
“Analog channels” in 1.3 of
Instruction Manual
85 Invalid search condition.
Check the search criteria
setting.
“6 Search Function” of
Instruction Manual
112 Aborted. – –
151
Message
No. Message Solution Reference page
113
Save processing was
interrupted.
Check the upper limit value of
the sampling rate for real-time
save.
Some storage devices may
have a slow writing speed,
causing real-time writing to fail.
Use another USB ash drive.
Connect a drive to a USB 3.0
connector.
“1.2 Conguring Measurement
Conditions” of Instruction
Manual
123
No data matching the search
criteria has not been found.
Check the search criteria
setting.
“6 Search Function” of
Instruction Manual
124
No waveform, or recording
length is not long enough.
Acquire measured waveform
data. Otherwise, specify a
correct recording length.
“3.2 Setting Measurement
Conditions” (p. 68)
“1.2 Conguring Measurement
Conditions” of Instruction
Manual
208 Server communication error.
Communications may be
unstable, or the instrument
may not support the email or
FTP servers running on the
server. The connection may be
established by enabling PASV
for the FTP or changing the
server security setting.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
209 LAN disconnected. Check the network environment.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
210 LAN timed out. Check the network environment.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
211 LAN authentication required.
The email or FTP server
authentication is required.
Enable the authentication.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
212 LAN authentication failed.
Logging in the email or FTP
server failed. The user name or
password may be incorrect.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
213 Authentication setup invalid.
The user name or password for
email authentication has not
been set.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
214 Encryption password not set.
Encryption is enabled, but a
password has not been set.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
215 Invalid server address. Check the address setting.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
216 POP3 Server not found.
Check the POP3 server
address.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
217
Cannot connect to POP3
Server.
Check the POP3 server
address. POP3 may not be
running on the specied server.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
218
E-mail ‘to’ or ‘from’ settings
invalid.
Check the recipient’s and
sender’s addresses of the email
setting.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
6
Maintenance and Service
152
Message
No. Message Solution Reference page
219 E-mail recipient error.
The server has refused to
send the email message to the
recipient. Check addresses
in the “to” eld. Check the
recipient’s address.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
221
The sent e-mail size exceeds
the limit.
The email size exceeds limits.
Reduce the recording length or
increase the size setting.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
222
E-mail size exceeds server
limits.
The sent email size exceeds
the email server limit. Reduce
the recording length or change
the attachment contents.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
223 FTP transfer failed.
Check the network environment.
The FTP server may have
rejected the le. Check the FTP
server setting. For example,
creating a directory (DIR) or le
is prohibited, or the server is
full.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
224 E-mail transfer failed.
Check the network environment.
The email server may have
rejected the email message.
Check the transmission
condition of the email server.
For example, the size or the
number of emails reaches the
limit of the server.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
225 Data send aborted.
The transmission is aborted.
Incomplete data may have been
transmitted via FTP or e-mail.
Check the transmitted data.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
226 Network error.
A network error occurred during
communication. Check the
network environment.
“11 Connecting the Instrument
to Computers” of Instruction
Manual
232
File processing could not be
successfully completed.
An unexpected error occurred
while a le in the USB ash
drive is being processed.
Replace the storage device with
another or cycle the instrument.
“2.5 Preparing Storage Devices
(Recording Media)” (p. 57)
235
Real-time save could not be
completed within available time.
Check the upper limit value of
the sampling rate for real-time
save.
Some storage devices may
have a slow writing speed,
causing real-time writing to fail.
Use another USB ash drive.
Connect a drive to the USB 3.0
connector.
“1.2 Conguring Measurement
Conditions” of Instruction
Manual
241 File processing error.
An unexpected error occurred
while a le in the USB ash
drive is being processed.
Replace the storage device with
another or cycle the instrument.
“2.5 Preparing Storage Devices
(Recording Media)” (p. 57)
601 Zero-adjustment required. Execute zero-adjustment.
“2.8 Regulating the Zero
Position (Zero-Adjustment)”
(p. 63)
606 Current sensor recognized. – –
