96
Managing Files
4.4 Managing Files
Opening the explorer allows you to manage data saved in storage devices.
Operation available on the explorer
Changing storage
devices
Storage devices can be changed.
Sorting les Files on a le list can be sorted based on the chosen basis.
Moving les to a
folder
Files can be moved to a folder of your choice.
Copying les or
folders
Files can be copied to a specied folder. When you choose folders to be copied, the
chosen folders are copied into the specied folder.
Creating a folder A new folder can be created.
Renaming a le
or folder
A le or folder can be renamed.
Deleting les or
folders
Files and folders can be deleted.
Format A storage device can be formatted.
To open the explorer
1
2
1
Click [Func].
2
Choose [Explorer].
Explorer appears.
Choose a storage device to be operated.
97
5
Conguring the Trigger Settings
The trigger function allows you to start and stop measurements using specic signals.
When recording is started by specic signals, it is called “The instrument is triggered.”
In this chapter, the mark
represents the point the start trigger is activated.
In the descriptions of each trigger source, the mark
represents a point each trigger condition is
satised and a point each trigger is generated.
When the real-time save is set to [On], you cannot use the trigger function.
> [Trigger] > [Common]
Operation available on the [Trigger] screen
Conguring the logic trigger settings
(p. 114)
• Logic-trigger satisfaction conditions
• Trigger lter
• Trigger pattern
Conguring the analog trigger settings
(p. 106)
• Level trigger
• Window trigger
• Period trigger
• Glitch trigger
• Voltage drop trigger
Conguring the trigger setting
• Trigger timing (p. 100)
• Pre-Trigger (p. 102)
• Trigger satisfaction condition (logical AND or OR
operation) among the trigger sources (p. 105)
Conguring the interval trigger settings
(p. 116)
Conguring the external trigger settings
(p. 118)
Forcible trigger (p. 118)
Trigger output (p. 213)
Conguring the trigger source settings
5 Conguring the Trigger Settings
5
Conguring the Trigger Settings
98
Trigger Setting Procedure
5.1 Trigger Setting Procedure
• The instrument is triggered based on trigger logical-conditions (logical AND or OR operation)
among trigger sources except for the forcible trigger. (p. 105)
• When triggered, the instrument outputs the TRIG OUT signal from the external control terminal.
(p. 213)
Congure the trigger function setting
Enables the trigger function. (p. 99)
Conguring the trigger timing setting
Specify the start timing of recordings
controlled by triggers.
(p. 100)
Conguring the pre-trigger settings
Specify a recording length that precedes
the start trigger point.
(p. 102)
Setting trigger logical-conditions (AND or
OR operation) among trigger sources
Setting trigger logical-conditions (AND or
OR operation) among the analog, logic,
external, and interval triggers to trigger the
instrument.
(p. 105)
Conguring the trigger type settings
Set trigger conditions for each trigger.
• Analog trigger (p. 106)
• Logic trigger (p. 114)
• Interval trigger (p. 116)
• External trigger (p. 118)
• Forcible trigger (p. 118)
Choosing a measurement mode
Choose whether the instrument repeatedly
waits for a trigger after a measurement has
been stopped.
(p. 6)
Starting a measurement
Click the start icon to start a measurement. (The key
green LED lights up.)
When a trigger condition is satised, the instrument
starts to acquire data.
To stop the measurement, click the stop icon.
Click the icon once: Stops the measurement once the
instrument has acquired the recording-length data.
Click the icon twice: Immediately stops the recording.
