193
Sending Data to a Computer With the FTP Client Function
Conguring an FTP server setting on a computer
The following example shows how to congure the FTP server settings on Windows 10.
The Microsoft
®
Windows
®
Home Edition does not include any FTP server. Use free software such
as the FileZilla Server.
• The setting contents may vary with environment. When necessary, refer to the help topics of the
FTP server or consult your network administrator.
• Microsoft
®
Windows
®
administrator privileges are required for setup.
Enabling the FTP
1
Start [Control Panel], and then
click [Programs].
2
Click [Turn Windows features on
or off].
The [Windows Features] dialog box
appear.
3
Click [+] on the left of [Internet
Information Services] to expand it.
Click [+] on the left of [FTP Server]
to expand it, and then choose [FTP
Service].
Click [+] on the left of [Web
Management Tools] to expand it,
and then select [IIS Management
Console].
Click [OK].
11
Connecting the Instrument to Computers
194
Sending Data to a Computer With the FTP Client Function
Conguring the FTP settings
4
Click [System and Security] on
[Control Panel].
5
Click [Administrative Tools].
6
Double-click [Internet Information
Services (IIS) Manager].
7
Right-click on the item displayed
under [Connections] on the left
side of the screen to display the
shortcut menu, then click [Add
FTP Site].
Communication may be blocked
depending on the settings of the
computer-protecting software (example:
rewall).
195
Sending Data to a Computer With the FTP Client Function
8
Enter site information.
Example:
[FTP site name]: [MR8740T]
[Content Directory]:
Choose a directory in which data from the
FTP client will be saved.
Click [Next].
9
Congure the [Binding] and [SSL]
settings as follows:
[IP Address] [All Unassigned]
[Port] [21]
[Start FTP site
automatically]
Select
[SSL] [No SSL]
Click [Next].
10
Congure the [Authentication and
Authorization Information] settings
as follows:
[Authentication] Select [Basic].
[Authorization] [All users]
[Permissions]
Choose both [Read]
and [Write].
Click [Finish].
11
Connecting the Instrument to Computers
