2.3.2 Deleting a Component ID (1) Select the component ID to be deleted. The selected component ID turns blue, indicating that it is se- lected. Fig. 3C6 (2) Press the [Delete...] button. The "Confirmation" dia…
*4 [Close] Button
When this button is pressed, the "Type Addition" window closes.
*5 [Change] Button
When this button is pressed, a component type is changed to the
contents entered in the "Type Name" and "Description" text boxes.
*6 [Delete] Button
When this button is pressed, the component type selected in "*2" is
deleted.
0305-001 3-8
AIM01EDTP
2.3 Basic Usage of the "Selection of component ID" Window
2.3.2 Deleting a Component ID
(1) Select the component ID to be deleted.
The selected component ID turns blue, indicating that it is se-
lected.
Fig. 3C6
(2) Press the [Delete...] button.
The "Confirmation" dialog box opens. When the [YES] button is
pressed, the selected component ID is deleted. Pressing the [NO]
button closes the "Confirmation" dialog box without deleting the
component ID.
2.3.3 Copying a Component ID
(1) Select the component ID to be copied.
The selected component ID turns blue, indicating that it is se-
lected.
(2) Press the [Copy...] button.
The "Copy Component ID" dialog box opens.
Fig. 3C7
Selected Component ID
2.3 Basic Usage of the "Selection of component ID" Window
0510-002 3-9 AIM01EDTP
(3) Enter a new component ID in the "New Component ID:" text box
and press the [OK] button. The original component ID is copied
and created as a new one.
2.3.4 Renaming a Component ID
(1) Select the component ID to be renamed.
The selected component ID turns blue, indicating that it is se-
lected.
(2) Press the [Rename...] button.
The "Rename" dialog box opens.
Fig. 3C8
(3) Enter a new component ID in the "New Component ID:" text box
and press the [OK] button.
The name of the original component ID is changed to the new
one.
2.3.5 Creating a Link ID
(1) Select the component ID as an original component ID before link-
ing.
The selected component ID turns blue, indicating that it is se-
lected.
(2) Press the [Create Link ID] button.
The "Create Link ID" dialog box opens.
Fig. 3C9
0305-001 3-10
AIM01EDTP
2.3 Basic Usage of the "Selection of component ID" Window
