4.2 "Nozzle Data" T ab The corresponding tab sheet enables the operator to set parameters to be used for recognition of various types of nozzles. It is required to register the nozzle data on the machine side b…
• Operation Procedure
Nozzle Type Change Operation
(1) Select the text box of "Head No." related to the nozzle (Nozzle
#) to be changed and double-click it.
The "Nozzle Type" window opens.
Fig. 3E57
(2) Select the nozzle to be allocated and press the [OK] button.
The selected nozzle type is set in the specified text box.
0305-001 5-68 AIM01EDTP
4.1 "Placement Head/Nozzle Data" Tab
4.2 "Nozzle Data" Tab
The corresponding tab sheet enables the operator to set parameters to
be used for recognition of various types of nozzles. It is required to
register the nozzle data on the machine side before parameter settings.
• Sheet Layout
When the "Nozzle Data" tab is pressed in the "Nozzle Data" window,
the following tab sheet appears inside the window.
Fig. 3E58 "Nozzle Data" Tab Sheet
• Sheet Composition
*1 Type
Displayed are the nozzle types.
*2 Shape Code
Displayed are the shape codes of the nozzles.
*3 O.D. Size [mm]
Displayed are the outside diameters of the nozzles.
*4 I.D. Size [mm]
Displayed are the inside diameters of the nozzles.
*5 Pick Face Image
Displayed are the image properties of the nozzle's pick faces.
0403-002 5-69
AIM01EDTP
*1
*2
*3
*4
*5
*6
*7
*8
4.2 "Nozzle Data" Tab
0403-002 5-70 AIM01EDTP
*6 Lighting Mode
Displayed are the lighting modes.
*7 V-Groove Size [mm]
Displayed are the V-groove sizes.
*8 Camera Mag.
Displayed are the camera magnification factors.
••
••
• List of Parameters
Table 3E2
4.2 "Nozzle Data" Tab
Shape
Code
Parame-
ter
O.D.
Size
[mm]
I.D. Size
[mm]
Pick
Face
Lighting
Mode
V-Groove
Size
[mm]
Camera
Mag.
Remarks
Nozzle
Type
Z011
Z021
Z031
Z041
Z052
Z062
Z071
Z081
Z101
Z124
Z552
Z901
Z911
Circle
Circle
Circle
Circle
Circle
Circle
Circle
Circle
Circle
Circle
Circle
Circle
Circle
0.9
1.8
6.0
3.0
1.3
2.5
1.3
0.6
1.3
0.7
1.3
2.6
0.6
Clear
Clear
Clear
Clear
Clear
Clear
Clear
Clear
Dark
Dark
Clear
Clear
Clear
Back/Front
lighting
Back/Front
lighting
Back/Front
lighting
Back/Front
lighting
Back lighting
Back lighting
Back/Front
lighting
Back/Front
lighting
Front lighting
Front lighting
Back lighting
Back/Front
lighting
Back/Front
lighting
0.7
1.1
4.5
2.0
0.9
1.2
0.9
0.4
0.4
0.2
0.9
1.8
0.4
High mag.
High mag.
Low mag.
High/Low
mag.
High mag.
High mag.
High mag.
High mag.
High mag.
High mag.
High mag.
High mag.
High mag.
V-Groove
V-Groove
For Front
Lighting Recog-
nition
For Front
Lighting Recog-
nition
V-Groove
Exclusively used
for bulk feeders
For Special
Specifications
For Special
Specifications
0
0
0
0
0.7
1.0
0
0
0
0
0.7
0
0
