E) Trigger time
In this entry filed the duration of the Trigger impulse can be determined.
F) Remove Code after
If the barcode from a PCB is matching to the actual loaded program/pro-
file a permission is set for that PCB. The permission is going after 10 sec-
onds if no PCB in front of the oven. More detailed explained the
permission is going after 10 seconds if there is no request signal from the
conveyor in front of the oven (SMEMA/Siemens interface). If the value in
that entry field is bigger than 10 seconds the value from the entry field is
used instead of.
Page 130 VISION XP+ VAC
5 Software
5.5 The Masks Menu
Operating Instructions
Version 1.5
5.5.14 Display PCB
Fig. 5-57 Display PCB
Present the actual PCB in the oven.
VISION XP+ VAC Page 131
5 Software
5.5 The Masks Menu
Operating Instructions
Version 1.5
5.5.15 Consumption Display
Fig. 5-58 Consumption Display
The current nitrogen and energy consumption will be indicated (each current
value, average of the last hour and sum of last 7 days).
