VISION XP+ VAC Page 155
6 Rehm Recorder
6.2 Live mode configuration
Operating Instructions
Version 1.5
6.2 Live mode configuration
6.2.1 Create new configuration
6.2.2 Edit configuration name
Fig. 6-4 Edit configuration name
First the configuration name and file name for the data packet stored must
be completed. These fields are mandatory.
It is also possible to configure start and end triggers. The type of trigger is
selected first.
Types can be selected to be a data point or time.
For a data point trigger, select the data point required and set the value
Fig. 6-3 Create new configuration button
The button
"Create new configuration" pro-
vides access to the Configuration
Wizard.
Page 156 VISION XP+ VAC
6 Rehm Recorder
6.2 Live mode configuration
Operating Instructions
Version 1.5
above or below which the trigger starts recording.
For a time trigger, specify the time recording starts.
It is possible for both trigger types to configure start and end triggers.
Fig. 6-5 Next button
This button moves on to the next
settings.
Fig. 6-6 Back button
This button moves back to the pre-
vious screens.
VISION XP+ VAC Page 157
6 Rehm Recorder
6.2 Live mode configuration
Operating Instructions
Version 1.5
6.2.3 Select data points
Fig. 6-7 Select data point 1
A) Clicking a switch activates the data points. The switch then turns blue
and the data point is shown on the far right in the list.
This is where all data points selected are displayed. Once a data point is
activated, a new list can be selected and additional data points activated.
The ">" arrow takes the user to the next input screen.
A
