Page 6 Vision XP+ VAC
1 Introduction
1.4 Overview of Revision Levels
Operating Instructions
Version 1.5
1.4 Overview of Revision Levels
Tab. 1-1 Revision Levels for Operating Instructions
1.5 System Description
The system is a fully automated, full convection reflow soldering system
which works with a nitrogen atmosphere. It allows for lead-free soldering.
The PCBs are advanced through various heat zones which are set to
different temperatures for preheating, soldering and cool-down.
The system is equipped with a graphic user interface and can be operated
with the included keyboard and touchpad, or optionally with a touch-screen.
Document Version Date
First draft Operating Instructions Reflow System 1.0 11/2012
Revision Operating Instructions Reflow System 1.1 05/2013
Revision Operating Instructions Reflow System 1.2 03/2014
Revision Operating Instructions Reflow System 1.3 12/2014
Revision Operating Instructions Reflow System 1.4 03/2015
Revision Operating Instructions Reflow System 1.5 09/2016
!
Note!
High grade, efficient insulation is used in the new generation XP+,
emphasising the environmentally friendly handling of resources. .
Vision XP+ VAC Page 7
1 Introduction
1.5 System Description
Operating Instructions
Version 1.5
1.5.1 Zones
Fig. 1-2 Zones
A) Inlet table with exhaust and filter
B) Preheating: 5 to 8 preheating zones, always heated from top and bottom
C) Peak zone: actual soldering zone, always heated from top and bottom
D) Cooling zone: cools PCBs and PCB components down
E) Outlet table with exhaust and filter
F) Additional refrigerated module (optional)
E
D
C
B
A
B
B
F
