07/2002 Editio n Student G uide HS -50 Advanc ed II 7 X-Axis 46  $ Q DOR J7 U DFN6LJ QDO V* DQWU \ $ [HV  0HDVXUHPHQW6HWXSRI$ QDORJ7 UDFN6LJQDOV   2VFLOORVFRSH6HWWLQ JV Inkrementalgeber X- …

100%1 / 431
Student Guide HS-50 Advanced II 07/2002 Edition
7 X-Axis
45
 &KHFNLQJWKHWUDFNVLJQDO
 7HVW(TXLSPHQW
1 dual channel oscilloscope > 20 MHz
1 track signal tester HS-50.
Plastic feeler gauge 0.4 mm
 2YHUYLHZ
$[HV 6HWWLQJ 2VFLOORVFRSH'LVSOD\
X read head adjusted to
0.4 mm,
parallel to scale
analog track signals:
digital track signal:
circuit with 1.8 V
diameter
pulse signals with
3.6 V
ss
and
90° degree phase
offset
Y read head adjusted to
0.4 mm,
parallel to scale
analog track signals:
digital track signal:
circuit with 1.8 V
diameter
pulse signals with
3.6 V
ss
and
90° degree phase
offset
07/2002 Edition Student Guide HS-50 Advanced II
7 X-Axis
46
 $QDORJ7UDFN6LJQDOV*DQWU\$[HV
 0HDVXUHPHQW6HWXSRI$QDORJ7UDFN6LJQDOV
 2VFLOORVFRSH6HWWLQJV
Inkrementalgeber X- / Y- Achse /
incremental encoder x- / y- axis
SIPLACE HS-50
Auflösung des Maßstabes: 1 Digit = 1 m
measuring scale: 1 dgt = 1 m
µ
µ
Spursignal - Teste
r /
track signal tester
BNC - Leitung
BNC line
track
zero pulse
analog
&KDQQHO 6LJQDO &RXSOLQJ <'HIOHFWLRQ 7ULJJHU ;'HIOHFWLRQ
CH 1
track A of
track signal
tester
DC 0.5 V/ DIV
x- / y- mode
auto 5 ms/ DIV
CH 2
track B of
track signal
tester
DC 0.5 V/ DIV
x- / y- mode
Student Guide HS-50 Advanced II 07/2002 Edition
7 X-Axis
47
 3URFHGXUH
Turn on the machine.
Relate your measurement setup to the x-, or y- axis respectively. (See ).
Adjust the oscilloscope.
Set the track signal tester to the "Oscilloscope cal" position.
With the help of the positioning switches CH1 and CH2, move the light spot exactly to the
center of the crosshairs of the screen.
Set the track signal tester to the "signal output" position.
Manually, move the appropriate axis (x = head / y = gantry) back and forth.
If you adjusted the read head correctly, the following illustration will appear on the screen of
the oscilloscope:
Spur A / track
A
Spur B / track
B
1,8- 2,0 V
