14 Conveyor System
55
14.4 Final Steps including Function Check
➠ 5HDGMXVWWKHSDUDOOHOLVPof the movable side of the conveyor to the fixed side if you ORRVHQHG
WKHSUHVVXUHIODQJHRQWKHEHDULQJKRXVLQJ in the course of work on the width adjustment
system(see Fig. 14.3.6 -> 1, 3, 4):
➠ Adjust the conveyor to an average width.
➠ Once again, loosen the screws fastening the accessible pressure flange of the pertinent
conveyor. One pressure flange each of the width adjustment system is to reach easy.
➠ Using a gage (e.g., adjustment plate) or a caliper gage, ascertain the distance between
movable and fixed conveyor side. The measurement points must be located above the cir-
culating spindles.
(see Fig. 14.3.6. -> 1).
➠ Manually turn the recirculating spindle at which the pressure flange was loosened until the
movable side of the conveyor - as established by a new measurement - is exactly parallel
to the fixed side.
➠ Fasten the movable side in place by tightening the pressure flange of the recirculating
spindle (3 cross-slotted screws M3 x 6).
Check: The entire width of the toothed belt must be engaged with the synchronizing disk.
and it must be in contact with the circumference of the deflection pulleys on its entire width.
➠ ,IWKHFXWWHUKDVEHHQUHPRYHG, you will have to re-install it as described in the service man-
ual, chapter "Cutter, Pneumatic" (see safety instructions in the above-named chapter).
➠ ,IWKHQR]]OHFKDQJHUKDVEHHQUHPRYHG, you will have to recalculate the nozzle changer
positions after the changer has been re-installed (SITEST program).
➠ Remove all tools, etc., from the working area of the machine.
➠ Where applicable, push the VWRSSHUback into the correct position (= FHQWHUHGto the width of
the conveyor). Carry out the necessary adjustments and a function check, GHSHQGLQJRQWKH
KRZWKHSUREOHPVZHUHUHVROYHG
– with the station software, transport menu / transport menu / width adj. system,
– with the aid of the SITEST program and on the basis of the "Setting Instructions for HS-50“.
