7. Dedicated Verification Devices and Communication

Edition 2.0 34 CP-7-series Verification System Instruction Manual

7. Dedicated Verification Devices and Communication

Dedicated devices (Handy Terminal, Setup Sensor & LED sequencer, feeder ID reader system)

for the Verification operation are connected to the machine by a dedicated serial

communication line. This communication status must be established correctly in order for the

optional devices to function.

This chapter explains the communication timing and the items to check when communication

errors occur.

7.1 When Using PDT-3100

This section does not apply to scanner types because there is no communication involved.

Communication timing

Communication with Handy Terminal (HT) occurs at the times shown below. The

phrase, "With HT setting" implies that verification system settings is specified as "With

HT".

• When the Handy Terminal power is turned on.

• When the re-connect command (7. TRY COMMUNICATION) is executed from the

Handy Terminal.

• When the [Device Check] button is pressed at the operation screen with a "With HT"

setting in effect.

Items to check when communication errors occur

• Check to see if the Handy Terminal cable is properly connected to the machine.

• Check to see if the wrong Handy Terminal connection port number has been

specified at the parts administration system settings screen.

• Verify that the version number which displays when Handy Terminal is started up

matches the machine’s control software version.

(If the versions do not match, upgrade the Handy Terminal’s software from the

machine’s peripheral device version upgrade screen (at machine control panel).

7. Dedicated Verification Devices and Communication

Edition 2.0 35 CP-7-series Verification System Instruction Manual

7.2 When Using Setup Sensor & LED Sequencer

Communication timing

Communication with setup sensor & LED sequencer occurs at the times shown below.

The phrase, "With setup sensor & LED sequencer" implies that verification system

settings is specified as "With setup sensor & LED sequencer".

• When the machine is started up (providing that a "With setup sensor & LED

sequencer" setting was specified at the previous power OFF).

• When the parts administration system settings screen is closed after the parts

verification system setting has been changed to "With setup sensor & LED

sequencer".

• When the connection port number setting is changed at the "Feeder Loading

Monitoring System" panel of the parts administration system settings screen.

Items to check when communication errors occur

• Check the parts administration system settings screen to see if the wrong connection

port number has been specified for the setup sensor & LED sequencer.

• Check to see if the cable connecting the sequencer to the machine is disconnected.

7.3 When Using Feeder ID Read System

Communication timing

Communication with feeder ID read system occurs at the times shown below.

• When the machine is started up (providing that a "With feeder ID read system"

setting was specified at the previous power OFF).

• When the parts administration system settings screen is closed after the parts

verification system setting has been changed to "With Fujitrax Verifier".

• When the connection port number setting is changed at the "Fujitrax Verifier setting"

panel of the parts administration system settings screen.

• When the feeder ID read system type is changed at the [Parts Administration

System] screen.

Items to check when communication errors occur

• Check the parts administration system settings screen to see if the wrong connection

port number has been specified for the feeder ID read system.

• Check to see if the cable connecting the feeder ID read system to the machine is

disconnected.

8. Verification Modes

Edition 2.0 36 CP-7-series Verification System Instruction Manual

8. Verification Modes

The CP-7 has 2 verification modes: standard verification mode, and quick verification mode.

This chapter explains the differences between these two modes.

8.1 Standard Verification Mode

Part barcodes are read and verified for each device, using the Handy Terminal connected to

the machine.

This mode can be used even if the Fujitrax Verifier system has not been installed. Although

verification is performed for the devices being used, the verification time for each device is

longer than when the quick verify mode is used.

Moreover, because only one Handy Terminal can be used, this mode is not suitable for

situations where two or more operators perform the device setup for a single machine (there is

a risk that the wrong feeder may be loaded).

With the Fujitrax Verifier used, the normal verification mode cannot be used when the Fujitrax

Verifier “Without DID” mode is in effect.

8.2 Quick Verify Mode

The following three quick verify modes are available.

1. Standard mode

2. DC AUTO mode

3. FULLAUTO mode

These settings can be made at the [Parts Administration System] screen using the

[Maintenance] - [Configuration] - [Machine Function Settings] - [Parts Administration System]

commands, and then selecting the [Fujitrax Verifier Settings] tab.

An explanation of each is provided below.

Nomal Mode

The DID is read using the Handy Terminal, and in the case where a DID Joint Symbol has not

been specified, the device comment is then read. In the case where a DID Joint Symbol has

been specified, the device comment is extracted from the DID. A comparison is then

performed between the extracted device comment and the device comment specified in the

production program.

DC AUTO Mode

The DID is read using the Handy Terminal, and in the case where a DID Joint Symbol has been

specified, the device comment is extracted from the DID. In the case where a DID Joint

Symbol is not used, the DID becomes the key ID and the device comment is acquired

automatically from Fujitrax Verifier. Acomparison is then performed between the acquired

device comment and the device comment specified in the production program.

FULL AUTO Mode

An association is formed in advance at Fujitrax Verifier between the feeder ID (FIDL) and the

part ID (DID). Unlike either of the above methods, there is no need to read either the DID or

the device comment when performing a device check. The feeders to be used in production

are loaded on the machine and the feeder Ids (FIDL) are read upon the commencement of auto

operation. The FIDL becomes the key ID and the device comment is acquired automatically

from Fujitrax Verifier. Acomparison is then performed between the acquired device comment

and the device comment specified in the production program.

Note: Ensure to confirm the Quick Verify mode settings after upgrading the machine control

software and make any changes if necessary.
