NPM
LNB
3.4 Result Information Display
EJM9BE-MB-03L-20 Page 3-25
3
Feeders, head, and nozzle changer
are displayed.
4
The target feeder, nozzle, and nozzle
changer are enlarged.
5
The whole of feeders, head, and
nozzle changer are displayed.
Display of target part
Explanation
a) For feeder
The color of the target feeder changes, and
it moves forward.
b) For nozzle
The head zooms in, the color of the target
nozzle changes, and it moves forward.
c) For nozzle changer
The nozzle changer zooms in, the color of
the target nozzle changes, and it moves
forward.
NPM
LNB
3.4 Result Information Display
Page 3-26 EJM9BE-MB-03L-20
②
When the target for error or warning is a tray cart
1
The cover opens.
2
The tray cart moves backward.
3
Trays, head, and nozzle changer are
displayed.
NPM
LNB
3.4 Result Information Display
EJM9BE-MB-03L-20 Page 3-27
4
The target pallet, nozzle, and nozzle
changer are enlarged.
5
The whole of trays, head, and nozzle
changer are displayed.
Display of target part
Explanation
a) For tray
The color of the target pallet changes, and it
moves forward.
b) For nozzle
The head zooms in, the color of the target
nozzle changes, and it moves forward.
c) For nozzle changer
The nozzle changer zooms in, the color of
the target nozzle changes, and it moves
forward.
