NPM
Safety Precautions
EJM9BE-SF-01N-21 Page S-3
z
Locations of safety switches
The optional tray feeder has two safety switches in the magazine door and the replenish
section.
N610074920AA
Safety switch in the magazine door
Replenish-section open/close switch
E-PD0101M1B
Disabled switches can lead to
accidents.
Do not disable safety
switches
DANGER
NPM
Safety Precautions
Page S-4 EJM9BE-SF-01N-21
z
Locations of safety switches
The NPM conveyor (dual conveyor) has one safety switch on the top cover.
DANGER
EJM9B-BB
Safety switch on the cover
E-PD0101M1B
Disabled switches can lead to
accidents.
Do not disable safety
switches
NPM
Safety Precautions
EJM9BE-SF-01N-21 Page S-5
If you sense any danger or abnormality, press an emergency stop switch to
stop operation.
If you continue to operate the machine in a dangerous or abnormal state, a breakdown or
an accident will occur.
z
NPM has two emergency stop switches. Pressing any one of them stops operation.
Press the nearest one.
When NPM is coupled, only one of the adjacent machines stops to ensure safety from the transport
apertures of the adjacent machines. (For details, see ‘Stopping specifications when coupled.’)
Eliminate the cause of danger or abnormality, and then restart operation. (Including the adjacent
machines)
To release, turn the emergency stop switch in the direction indicated by the arrow.
M107B
DANGER
EJM9B
-
AA01
Adjoining machine that stops
Adjoining machine that does not stop
When three machines are coupled
EJM9B-AB01
Emergency stop switch
(At the rear side)
Emergency stop switch
(At the front side)
