NPM
Safety Precautions
EJM9BE-SF-01N-21 Page S-7
Observe the following precautions in handling linear motors.
Magnetic force may cause injuries and accidents. It may also cause burns.
z
NPM uses linear motors for driving along its X- and Y-axes.
z
Since extremely powerful permanent magnets are used in the linear motors, wrong handling can be
extremely dangerous even if the main power supply is in the OFF state.
In working inside the safety covers (e.g. in maintenance), follow the rules below.
1. Those who wear pacemakers must not work inside the safety covers.
2. In working, do not wear any metals such as watches, pierced earrings, and necklaces.
3. Since the movers of linear motors become hot (80°C under 25°C environment, 90°C under 35°C
environment), take care not to suffer burns.
z
After shutdown, it may be three hours or more before they reach room temperature.
4. Do not disassemble the linear motors.
z
Since the attractive power of the stators (the magnets) is extremely powerful, disassembling
them can be extremely dangerous.
M126B
DANGER
N610052923AA00
X-axis linear motor
X-axis mover
X-axis stator (magnet)
EJM9B-AM00
Y-axis stator (magnet)
Y-axis linear motor
Y-axis mover
NPM
Safety Precautions
Page S-8 EJM9BE-SF-01N-21
EJM9B-AZ00
Do not put your hands in the openings between feeders installed.
Your hands may be injured by the moving parts in the machine.
z
We recommend installing all feeders so that you will not accidentally put your hands into the machine.
M114
WARNING
NPM
Safety Precautions
EJM9BE-SF-01N-21 Page S-9
EJM9B-AB01
In maintenance, be careful not to receive an electric shock.
Even if the main power supply switch is OFF in maintenance, the power is still supplied as
far as its primary line; therefore, you may receive an electric shock.
M111B
WARNING
Primary line
(Power is still supplied.)
L1
L2
L3
PE
Main terminal
Main power supply switch
Primary line
(Power is still supplied.)
L
N
PE
Main terminal
Main power supply switch
EJM9B-AG02
LNB conveyor (option)
HUB conveyor (option)
∗
When you turn off the main power,
also the air pressure source is interrupted synchronously.
E-PW0104M1B
Failure to observe this can lead
to electric shock and other
accidents.
Shut off power and air
supply at the source
before performing
maintenance
PW0133M1B
Keep all tools, ornaments and
other metal objects away form
the linear motor.
Risk of injury due to
Magnetic force
PW0134M1B
Risk of accidents caused by
errors in operation due to
magnetics force
Individuals with
pacemakers, etc.
should keep away from
the linear motor
