NPM
LNB
4.3 Advanced Setting
EJM9BE-MB-04L-20 Page 4-21
4.3.8 Time setting
Set the time of LNB.
1
Click [Time Setting] in [Advanced]
from the menu.
•
<Time Setting> screen is displayed.
At the top of the screen, the current time of
LNB is displayed.
2
Enter [Time Zone], [Date and Time]
and [NTP Server Connected to], and
click [Apply].
3
If you have changed the time zone,
click [OK] on the confirmation screen
on which the message for restarting
the LNB system appears.
4-3029
1
4-3030
2
4-3031
3
NPM
LNB
4.4 Setting Information Backup
Page 4-22 EJM9BE-MB-04L-20
4.4 Setting Information Backup
You can back up the setting information of LNB.
The setting information backed up here can be loaded by ‘setting information restore.’
1
Choose [LNB] in [Backup
Configuration] from the menu.
•
The <Backup LNB configuration> screen is
displayed.
2
Click [Save].
•
The file download dialog opens.
3
Click [Save].
•
A dialog prompts for the destination to save.
Specify the destination, and download it.
•
If the file download dialog does not open, click
the link shown left that appears on the <Save
LNB setting information> screen.
lnb4-4001_e
1
lnb4-4002_e
2
lnb4-4003_e
3
lnb4-4004_e
NPM
LNB
4.5 Setting Information Restore
EJM9BE-MB-04L-20 Page 4-23
4.5 Setting Information Restore
You can load the LNB setting information.
The setting can be applied by specifying the backup LNB setting information.
1
Choose [LNB] in [Restore
Configuration] from the menu.
•
The <Restore LNB configuration> screen is
displayed.
2
Click [Browse] to specify the location
of the LNB setting information.
•
A dialog prompts for the setting information
file. Specify the setting information file.
3
Click [Restore].
•
The confirmation dialog opens.
4
Click [OK].
•
The reconfirmation dialog opens.
5
Click [OK].
•
When the restore is complete, the message of
load completion appears.
∗
After this, LNB is restarted automatically.
Because the screen will not be refreshed after
LNB is restarted, wait for about one minute
and then log in again.
lnb4-5001_e
1
lnb4-5002_e
2
3
lnb4-5005_e
lnb4-5003_e
4
lnb4-5004_e
5
