• Action of the Function Keys + P AGE : Press to display the next page. - P AGE : Press to display the pr evious page. ▲ : Press to move the cursor up one line. ▼ : Press to move the cursor down one line. ESCAPE : Block …
FCP IV-3 Operation
(a) : Device number
(b) : Parts status
Un Set (yellow display) : Parts not yet checked.
Blank (green display) : Parts set
(blue display) : Device previously used is not to be used this time.
Next D (magenta display): Set as next device but not checked
Tape E (white display) : End of tape detected
Parts E (red display) : Out of parts
Pickup (highlighted in yellow) : Parts mispicked
Vision (purple) : Vision processing error
(c) : Number of parts per board
(d) : Device comment
Chapter 3 Description of Commands
Part 3
3 – 33
Version 5.0
• Action of the Function Keys
+ PAGE : Press to display the next page.
- PAGE : Press to display the previous page.
▲ : Press to move the cursor up one line.
▼ : Press to move the cursor down one line.
ESCAPE : Block check of all remaining unset parts. Press
to escape from the device check mode. This
function is only enabled if the ESC_Permission
Proper value is set to 1.
RETURN : Press to return to Page 451/000.
• First Status Area
DEVICE CHECK
• First Display Area
(a) (b) (c) (d)
D001 Un Set [0013] Device_comment_No_1
D002 Parts E [0008] Korewa_No2_Desu
D003 [0002] PCPR102TL
D004 [0000]
D005 Vision [0001] MSD2HD256
D006 Tape E [0005] Micro_Tr_Nol
D007 Next d [0000] Super_Mini_Tr
D008 [0002] Nihongonetute
D009 Pickup [0003] N3456Sd23
D010 [0015] Jaf
• Function Key Menu
Chapter 3 Description of Commands
To Page 451/000
Device Check Mode 1
Part 3
3 – 34
MODE 1
Page
451 100
+PAGE -PAGE
▲
▼
ESCAPE RETURN
Version 5.0
FCP IV-3 Operation
FCP IV-3 Operation
The operation of this command varies according to the settings of the
following Proper values.
Proper Value No. 71 Verifier_tool
Non : Handy Terminal is not used.
Proper Value No. 74 ESC_Permission
Non : The [ESC] key is enabled in order to set all parts which are
Un Set.
Permit: The [ESC] key is disabled.
Proper Value No. 75 MAN_permission
Non : Input from the operation panel is enabled.
Permit: Input from the operation panel is disabled.
The [CR] Key and numerical keys are enabled when this Proper value is set to
[Permit].
If the device number is input from the numerical keypad followed by the
[CR] key, the "Un Set", "Parts E", "Tape E", "Pickup", or "Vision" display for the
input device number is cleared.
If the cursor is moved to a device number using the function keys, the parts
status display for that device number can be cleared only by pressing the CR
key.
Proper Value No. 70 Device_Check_SW
Non : Device check does not start automatically when production
begins.
Parts : Device check starts automatically if parts are out when
Miss : production begins. If the [RETURN] key is pressed before
Error : device check has been completed the machine does not enter
the [START] button wait mode. It enters the Ready mode.
Chapter 3 Description of Commands
Part 3
3 – 35
Version 5.0
