Appendix A I/O Map
A – 13Version 2.0
SX000 NO1 EMERGENCY Number 1 servo board emergency stop input
SX001 Not currently in use
SX002 Not currently in use
SX003 Not currently in use
SX004 Not currently in use
SX005 Not currently in use
SX006 C AXIS ZERO Cam axis zero setting button
SX007 Not currently in use
SX008 Not currently in use
SX009 Not currently in use
SX00A Not currently in use
SX00B Not currently in use
SX00C Not currently in use
SX00D Not currently in use
SX00E Not currently in use
SX00F Not currently in use
Servo Input 1 (C,FQ Axes)
LED No. Display Description
Appendix A I/O Map
Version 2.0 A – 14
SX010 NO2 EMERGENCY Number 2 servo board emergency stop input
SX011 Not currently in use
SX012 Not currently in use
SX013 Not currently in use
SX014 X AXIS +OT X axis (+) overtravel
SX015 X AXIS -OT X axis (–) overtravel
SX016 X AXIS ZERO X axis zero setting button
SX017 X AXIS READY Y axis interlock
SX018 Y AXIS +OT Y axis (+) overtravel
SX019 Y AXIS -OT Y axis (–) overtravel
SX01A Y AXIS ZERO Y axis zero setting button
SX01B Y AXIS READY Y axis interlock
SX01C Z AXIS +OT Z axis (+) overtravel
SX01D Z AXIS -OT Z axis (–) overtravel
SX01E Z AXIS ZERO Z axis zero setting button
SX01F Not currently in use
Servo Input 2 (X, Y, Z Axes)
LED No. Display Description
Appendix A I/O Map
A – 15Version 2.0
SX010 NO3 EMERGENCY Number 3 servo board emergency stop input
Sx021 Not currently in use
SX022 Not currently in use
SX023 Not currently in use
SX024 D1 AXIS +OT D1 axis overtravel in positive direction
SX025 D1 AXIS -OT D1 axis overtravel in negative direction
SX026 D1 AXIS ZERO D1 axis zero setting sw
SX027
SX028 D2 AXIS +OT D2 axis overtravel in positive direction
SX029 D2 AXIS -OT D2 axis overtravel in negative direction
SX02A D2 AXIS ZERO D2 axis zero setting sw
SX02B
SX02C Not currently in use
SX02D Not currently in use
SX02E Not currently in use
SX02F Not currently in use
Servo Input 3 (D1, D2 Axes)
LED No. Display Description
