4.3.2 Cycle Stop (During Automatic Operation)
This is the display when a cycle stop occurs.
Press this button during automatic operation to cancel the
automatic operation mode at the end of the current sequence. The
message “Waiting for Reset SW” appears along with a brief
description of the problems on the machine. After the source of the
problem has been removed, press the [RESET] switch, and the
“Press START” message will appear.
Note: When a cycle stop occurs, refer to Part 6, Chapter 1 of this
manual.
Waiting for Reset SW
D100 Resupply
Skip Nozzle
S ABCDEFGHIJKL
M ABCDEFGHIJKL
L ABCDEFGHIJKL
Tape End
000 000
000 000
000 000
1 – 29
FCP IV-3 Operation
Chapter 4 The Display
Version 5.0
Part 1
4.3.3 Other Interruptions During Automatic Operation
There are instances when the FCP IV-3 will be interrupted during
automatic operation because of one of the following two reasons.
(1) If calculation of placing data does not finish in time
If by chance the calculation of data used in placing parts does
not finish in time, automatic operation will be interrupted until
these calculations have been completed. In this case the
message "Calculating Placing Data" will display on the screen.
Once these calculations have finished, return to automatic
operation and start again.
(2) If vision processing does not finish in time.
If vision processing is not completed in time, automatic
operation will be interrupted until processing has been
completed. In such a case the message "Vision Processor
Executing" will display on the screen. Once vision processing
has finished, return to automatic operation and start again.
ST7.N 1 D 35
Vision processing
STATUS
P Mode Product
Recovery 3 Times
T Mode Joint
ST7.N 1 D 35
Placing data calculations being processed
STATUS
P Mode Product
Recovery 3 Times
T Mode Joint
1 – 30
FCP IV-3 Operation
Chapter 4 The Display
Version 5.0
Part 1
4.3.4 Press START
During Automatic or Step mode, when the command position has
been chosen and the machine can safely carry out the operation
requested, the “Press START” message will appear. The operator
must then press the [START] button.
4.3.5 When the Machine Cannot Run
The following display will appear when the machine cannot start
its next function. When the problem displayed has been fixed the
“Press START” message will appear. Pressing the [RETURN]
command key will restore the former situation without solving the
problem.
Note: When this situation occurs, refer to Part 6, Chapter 1 of this
manual.
Front Safety Door
Skip Nozzle
S ABCDEFGHIJKL
M ABCDEFGHIJKL
L ABCDEFGHIJKL
Tape End
000 000
000 000
000 000
Press START
Skip Nozzle
S ABCDEFGHIJKL
M ABCDEFGHIJKL
L ABCDEFGHIJKL
Tape End
000 000
000 000
000 000
