Introduction

Scope of Functions with Fixed Setup and Constant Tables

130 ASM Material Setup Assistant 2.3 (R17-1) ASM Material Setup Assistant 2.3

1.2

1.2 Scope of Functions with Fixed Setup and Constant Tables

Scope of Functions with Fixed Setup and Constant Tables

SIPLACE Material Setup Assistant (MSA) with fixed setups and constant tables is supported; however,

the workflow needs to be adapted and the scope of functions of SIPLACE Material Setup Assistant

(MSA) is different. See chapter "6 Workflow with Fixed Setup and Constant Tables" [ ➙ 225] for a de

scription of the deviations in the workflow and the scope of functions.

Overview

In contrast to flexible family setups, fixed setups are installed once and reused several times without be

ing torn down in the meantime. Changeover tables for a fixed setup are usually "parked" near the line as

long as they are not in use. The material on these tables is not used elsewhere apart from a few excep

tions (e.g. the last present reel). As soon as the fixed setup is no longer in use, all changeover tables are

torn down and the material is returned to the warehouse.

Constant tables function in a similar way, with the additional option of combining flexible and constant

tables at the relevant locations. A constant table is installed once and reused several times. Usually, the

constant table is used in different setups. In a typical scenario, e.g., one side of the line is set up with

constant tables and the other side with flexible tables. As soon as the constant table is no longer in use,

it is torn down and the material is returned to the warehouse.

Features

▪ Changeover tables for fixed setups and constant tables are always linked to a line. They cannot be

used on a different line.

▪ Reusing material in the presetup area is not relevant as the constant tables are usually parked near

the line.

▪ Material for fixed setups and constant tables is usually not stored on the AFP hardware (feeder racks

or docking stations). After the production, these changeover tables are simply "parked" near the line

without being torn down.

▪ Planned fixed setups and constant tables cannot be used in the next but one setup (n+2 rule in flex

ible family setups). These changeover tables can only be used in directly successive setups; in most

cases, they are kept near the respective station.

Introduction

Scope of Functions With ASM Material Manager

ASM Material Setup Assistant 2.3 (R17-1) ASM Material Setup Assistant 2.3 (R17-1) 131

1.3

1.3 Scope of Functions With ASM Material Manager

Scope of Functions With ASM Material Manager

ASM Material Manager is available in two versions.

ASM Material Manager - Full Version

With the full version, you perform the storage management with the ASM Material Manager. The material

flow in the factory is controlled totally and completely automatic.

▪ Material order via material demand lists.

▪ Automatic pick-up from the relevant storage equipment (e. g. SIPLACE Material Tower).

▪ Controlled transport of the material (via PDAs) into the pre-setup area and back.

ASM Material Manager for MSA

With the ASM Material Manager for MSA, you control the material flow in the factory yourself. Based on

the setup lists from ASM Setup Center, you trigger the order, the transport, and the handover of the ma

terial into the setup area. You can use the scan procedures Sort material and Record material to enter

the material in ASM Setup Center.

See also "5.8.3 Sorting and Recording Supplied Material" [ ➙ 213].

1.4

1.4 SIPLACE Material Setup Assistant Benefits

SIPLACE Material Setup Assistant Benefits

Reduction of material movement between warehouse and presetup area

Material demand lists are created in the Order Manager. These are automatically sent to the ASM Ma

terial Manager, in accordance with the production order. Warehouse picking is performed with the ASM

Material Manager.

▪ Only the material which is not already in the presetup area or at the relevant line will be picked from

the warehouse.

▪ Only the material which is not required anymore in the production schedule will be placed back in

the warehouse.

Reduction of presetup work due to reuse of materials

Material reuse in the presetup area reduces the setup work considerably. The setup work in the pre-set

up area and in the warehouse is reduced by each individual reuse of a material.

Efficient user guidance with status LED display on the feeders

The status LEDs of the SIPLACE Material Setup Assistant indicate the most important information for

the operator.

Fewer materials opened or sent back to warehouse

The reuse of materials means that material often remain in the presetup areas of the lines. This reduces

the number of opened materials in the warehouse.

Introduction

Functional Limits

132 ASM Material Setup Assistant 2.3 (R17-1) ASM Material Setup Assistant 2.3

Automatic synchronization of the production schedule and monitoring of production progress

by the Order Manager

SIPLACE Material Setup Assistant automatically distributes information about the production schedule

to the following areas of your production environment:

▪ Production/line

– Update of production schedules in the SIPLACE Line Control GUI on the lines.

▪ Presetup area

– Order of setups to be prepared in ASM Setup Center GUI plus determination and display of ma

terial reuse status in the Active Feeder Pool.

▪ Warehouse

– Generation of material demand lists for the warehouse in the ASM Material Manager.

This means that the production scheduler no longer needs to manually communicate the production

schedule to the various process stages. The production scheduler can monitor the progress of the pro

duction schedule with the help of Gantt diagrams in the Order Manager.

1.5

1.5 Functional Limits

Functional Limits

General Information

The following functions are only supported to a limited degree or not all in SIPLACE Material Setup As

sistant 2.3:

▪ With S-type feeders, material reuse is only possible to a limited degree. (See "8 Mixed Operation of

S Feeders and X Feeders in a Line" [ ➙ 239])

▪ Conversion with uninterrupted feeder changeover at the line (floating setup)

With ASM Material Manager for MSA

The following workflow steps are NOT supported in SIPLACE Material Setup Assistant 2.3 in combina

tion with ASM Material Manager for MSA.

▪ ASM Material Manager for MSA does not create material demand lists.

▪ With the ASM Material Manager for MSA, material CANNOT be picked from the warehouse.

▪ Reordering refill material is not possible via the ASM Material Manager for MSA.

▪ Material CANNOT be put into the warehouse with the ASM Material Manager for MSA.

NOTICE

ASM Material Manager - Full Version Only

Material requirement lists can only be created with the ASM Material Manager - Full Version.

NOTICE

Use of multiple-track feeders

Feeders with more than one track (e.g. the SIPLACE SmartFeeder 2x8 mm X) are not recom

mended for use in flexible family setups. However, in fixed setups and on constant tables, these

feeders are recommended.
