Getting Started and Overview of the Order Manager
Production Order Manager
ASM Material Setup Assistant 2.3 (R17-1) ASM Material Setup Assistant 2.3 (R17-1) 179
4.2.5
4.2.5 View - Edit
View - Edit
► Go to the View toolbar and select the Editing icon.
⇨ Switches over to the Edit view.
You can edit jobs in the Edit view.
► For a description of the functions for View, SIPLACE Pro, Filter and Options in the toolbar, refer to
"4.2.2 Overview - Production Order Manager" [ ➙ 174].
The following additional Filters are available:
The following actions are possible:
4.2.6
4.2.6 Import Job - SIPLACE Pro
Import Job - SIPLACE Pro
The existing SIPLACE Pro jobs will be shown in this tree structure. Depending on the filter settings, you
will either see all jobs present in SIPLACE Pro or only those jobs for certain lines. See also "4.2.7.2 Di
-
alog - Line Filter Options" [ ➙ 180].
The jobs selected in the tree structure can be imported via the function Import Jobs. A production
job will be created with a job number (ID). These production jobs will be shown in the job list.
If jobs have already been imported, a message will be shown with these imported jobs. These job/reci
-
pes can then be ignored during the import procedure.
You can drag and drop the selected jobs into the the job list. This enables you to insert the new jobs
between the existing ones.
Filters Description
Show history Also shows the jobs which have already been done or canceled.
Action Description
Lot size Enables you to change the size of a batch. This change to the batch size also
changes the material requirements and and production duration of the job. The
end time for the job is adjusted accordingly.
Mark the required production job and enter the new value. Confirm with the En
-
ter button.
Comments Enables you to add a text to a production job. Mark the required production job
and enter the text here. Confirm with the Enter button.
The text will be shown in the Remark column.
Lane In a production line with two conveyor tracks, you can select here if a produc
-
tion job is to be produced either on the left track or on the right track or simul
-
taneously on both tracks.
Recall
Jobs which have already been approved will be reset. In order for approved
jobs to be edited or deleted, you need to reset them with this function.
Delete
Deletes a selected job from the list. Only those jobs can be deleted which have
not yet been started or which have already been completed.
Getting Started and Overview of the Order Manager
Production Order Manager
180 ASM Material Setup Assistant 2.3 (R17-1) ASM Material Setup Assistant 2.3
4.2.7
4.2.7 Dialogs
Dialogs
4.2.7.1
4.2.7.1 Dialog - Compress
Dialog - Compress
Call using:
► Production Order Manager => Compress.
Select the setting which you want to use for . Compressing eliminates time gaps between the jobs. The
approved jobs in the timeline are collected together so that no additional pauses exist.
4.2.7.2
4.2.7.2 Dialog - Line Filter Options
Dialog - Line Filter Options
Call using:
► Ribbon bar icon at Production Order Manager => Filter.
Enables you to filter the jobs shown in the SIPLACE Pro jobs tree structure.
4.2.7.3
4.2.7.3 Dialog - Timeline Options
Dialog - Timeline Options
Call using:
► Ribbon bar icon at Production Order Manager => Timeline.
Select the options for showing the data in the timeline.
Option Status
Compress all man
-
ufacturing orders
All jobs in the jobs view will be compressed in the timeline according to their sched
-
uled starting times.
Compress from
selected manufac
-
turing order
The selected job and all following jobs will be compressed in the jobs view timeline
according to their scheduled starting times.
Compress only the
selected manufac
-
turing order(s)
The selected jobs will be compressed in the jobs view timeline according to their
scheduled starting times.
Function Status
Filter SIPLACE
Pro Jobs for the
selected line
Active: The SIPLACE Pro jobs tree structure only shows the jobs for the selected
line.
NOTICE!
These filter options may take some time when they load for the first time, depend
-
ing on the volume of data.
Disabled: The SIPLACE Pro jobs tree structure shows all the jobs present in
SIPLACE Pro.
Function Status
Past Days Choose for how many past days you want to see the timeline.
Getting Started and Overview of the Order Manager
Production Order Manager
ASM Material Setup Assistant 2.3 (R17-1) ASM Material Setup Assistant 2.3 (R17-1) 181
4.2.7.4
4.2.7.4 Dialog - Search
Dialog - Search
Call using:
► Production Order Manager => Search.
Or
► Monitoring => Search.
Enter one more more of the search terms which you want to use. You can use the characters * and ? as
wildcards to find similar terms.
All matching entries will be highlighted in the jobs view or the timeline. If necessary, the view will be
moved accordingly in the timeline.
4.2.7.5
4.2.7.5 Dialog - Import selected recipes
Dialog - Import selected recipes
Call using:
► Production Order Manager => Import Recipes.
Individual recipes or recipe groups can be imported . This is helpful if you want to import individual rec
-
ipes in jobs which contain a lot of recipes.
Element Description
ID Searches in the ID column for the required number.
Setup Searches in the setups for the search term.
Recipe Searches in the recipes for the search term.
Board Searches in the boards for the search term.
NOTICE
The main window stays opened.
You can continue working in the main window while the Search dialog is opened.
Filters Description
Recipe Limits the number of displayed recipes. Enter the relevant term. You can use the
characters * and ? as wildcards to find similar terms.
Ignore path Hides the path in the list of Available Recipes.
Apply Filter The pre-defined filter settings are applied.
Element Description
Available Recipes Displays all recipes for the selected job. The display is reduced depending on the
filter setting.
Mark the required recipes and add these to the list Selected Recipes using the >
and >> buttons.
Selected Recipes: Shows the recipes which have been selected for the import. All recipes in the list
are imported.
You can exclude recipes from the import and move them to the list of Available
Recipes using the < and << buttons.
Import Starts importing the recipes which were added to the list Selected Recipes.
