第 1 部基本篇第 1 章装置概要

1-1

第1章装置概要

1-1 本装置概要

1-1-1 前言

KE-3010A/3010AC/3020VA/3020VRA 是下一代高速模块式贴片机生产线的核心，继承了以往构筑

的模块化概念的灵活性能，令安全性、可靠性、维护性、经济性进一步提高的逐片式多连式工作头

（Head）型通用贴片机。

KE-3010A/3010AC/3020VA/3020VRA，与高速模块贴片机 FX-3RA 亲和性强，安装电动式供料器可

构成高品质、高水平的生产线。可使用原 KE 系列使用的元件供应装置（带状、管状、散装）以及生

产程序，有利于降低引进成本，易于启用。

KE-3010A/3020VA/3020VRA 具有可高速无间断画像功能的 S-VCS，与敝公司原有设备相比，可提

高识别速度最大达 61％（本公司指定的 IC 元件）。

此外，通过组合生产支援系统「IS」（Intelligent Shopfloor Solutions 智能车间解决方案）、「IFS-NX」

（Intelligent Feeder System 智能供料器系统）可对贴片机及点胶机上与生产相关的各种业务和信息，

以车间（＝制造现场）为单位进行综合管理、优化，支援提升整体车间的生产性、制造品质，实现提

高效率，降低成本。

※ 有关「IS」的详细功能说明，请参见『IS 机器规格书』。

※ 有关「IFS-NX」的详细功能，请参见『IFS-NX 机器规格书』。
