注意

1. 本装置配备有 ATX，以保护停电时的生产程序等。

为防止 ATX 内置电池劣化，请勿在非通电状态下将本装置放置 6 个月以上。

●本装置以电流总断路器及总开关 ON 的状态为通电状态。

注意

1. X 轴、Y 龙门架轴上使用磁力线性编码器（磁性尺）。

・不要使金属类接近磁石面，因可能被磁石吸住，金属类取不下来。

・进行维护时，请摘下身上的手表等精密机器。

・使用心脏起搏器等精密医疗器者，不能从事维护工作。

・不要将带有磁石、磁力的螺丝刀等工具接近磁性尺。

・因为支撑销使用磁石，所以请勿将其接近磁尺。由于磁力，可能损坏磁性尺。

注意

1. 因为电离装置要产生离子，所以电极部分处于高压状态。积累的静电会对人体放电，

造成触电，所以在接通电源时请不要靠近或进行清扫。

为了安全使用机器
