Safety Precautions
No. Alert Labels and Description
(7)
Description
z Before operating the machine, please read the instruction manual carefully for
correct operations.
An operator's error will break down the machine, causing an injury or a serious
accident.
(8)
Description
z Pay attention to the moving mechanisms. Otherwise, you may be trapped by the
moving mechanisms and a serious accident will result.
Description
z When a cover (door) is opened or closed, be sure to hold the grip firmly and slowly
move the cover up or down. Otherwise, part of your body (hand, etc.) may be
trapped in the cover.
WARNING
WARNING
Please read the instruction manual
carefully for correct operation.
An operator's error may result in
machine damage or injury.
8-28-1
0506-002
8-3 8-4
Safe-20
Safety Precautions
No. Alert Labels and Description
(9)
Description
z Before the machine is powered, be sure to connect a ground wire correctly to avoid
an electric shock.
Imperfect grounding will cause an electric shock.
(10)
Description
z Do not lean your body against the wheel of the bank feeder change cart. Otherwise,
the wheel will fall apart, causing an injury.
(11)
Description
z Do not bring a magnetic card or a watch close the labeled area.
Strong permanent magnets are used in the moving mechanisms of the X- and Y-
axis linear sections.
The data of the magnetic card might be cleared or a watch, etc., may be damaged
due to the strong magnetism.
CAUTION
CAUTION
Keep any magnetic card away from this.
Otherwise, the data may be cleared.
Strong Magnetism!
A watch, etc., may also be damaged.
0506-002
WARNING
WARNING
High Leakage Current!
Earth Connection Essential
before Connecting Supply
Safe-21
Safety Precautions
No. Alert Labels and Description
(12)
Description
z Keep the linear guide grooves clear of any object. Otherwise, an object in the
groove may be trapped in the moving part, causing the machine to be damaged.
(13)
Description
z Be sure to attach or detach the feeder carefully with both hands. Otherwise, the
feeder may fall down and break. You may also be given an injury.
(14)
Description
z Keep your head away from any corners such as those of the operation panel.
Otherwise, a corner may hit you on the head, etc., and you will be given an injury.
(15)
Description
z For transportation, the arms of a fork lift truck or a catch pallet must be inserted
from the front or rear side of the machine.
If the arms or the catch pallet is inserted from the side face of the machine, the
electrically equipped sections may be damaged.
CAUTION
CAUTION
Keep Linear Guide Grooves
Clear of Any Object!
An object in the groove may be trapped in
the moving part, causing the machine to be
damaged.
CAUTION
CAUTION
Special Care Required for
Feeder Handling!
The feeder will also be damaged.
If a feeder slips out of your hands, an injury
will result.
CAUTION
CAUTION
Pay attention to the
overhead location and
corners.
CAUTION
CAUTION
Forklift Forks Insertion Prohibited
Do not insert the forks of a forklift truck from
this direction.
If the forks are inserted, the electrically equipped
sections may be damaged.
0506-002
