Safe-32

Safety Precautions

0506-001

z The machine must be operated by the person who made the pattern program

data and no one else should work as his/her substitute.

Every movement of the machine is determined by the pattern program data specified

as a current one.

If an operator who does not fully understand this data operates the machine as a

substitute of the data creator, there is a possibility to cause various misunderstandings.

This is something like asking someone else in place of you to drive a car in

darkness on a road that has no traffic signs.

z Be sure to turn off the power before leaving the machine unattended in the

middle of a test run.

Although you intend to leave the workplace for a short period of time, you may not be

able to come back for many hours. This happens frequently in our daily life.

After you have left the workplace, it cannot be avoided that someone else may operate

the machine.

Never leave the machine along with the power being turned ON, the safety doors

being unlocked, and the sensors being deactivated.

Be aware that you are charged with some responsibility not only for your co-workers

but also for the others.

z When some safety area sensors, safety covers, etc., must be detached

inevitably from the machine for servicing work, the machine and the

hazardous areas must be kept inaccessible to any person on the customer

side.

We never know when a person on the customer side enters the hazardous areas of the

machine (with the safety doors being open and the sensors being deactivated) during

our servicing work.

Keep the hazardous areas inaccessible, using a barricade tape, etc.

Note

Safe-33

Safety Precautions

0506-001

z Before performing a test run, it is required to set parameters to control the

variations in the movement based on the results of detection during the

operation.

Execute a test run for the running-in and performance check of the machine.

Before performing a test run, make the following settings in the "Test Mode" window

to prevent the machine from being activated in an unexpected way.

z Tick the "Missing Cmpnt Det Disabled", "Vertical Cmpnt Det Disabled", and

"Cmpnt Recog Pseudocomm" check boxes in the "Test Mode" window.

z Set parameters to prevent the machine from being set in the "Component

Replenishment", the "Recovery", or the "Alternate" mode.

Special caution should be paid to your maintenance work when test run

is performed with the covers being opened or the sensors being

deactivated.

z Be sure to keep your body away from the movable range of the machine

during operation.

z Do not disable the interlock unless absolutely necessary.

It is very dangerous if your work requires you to disable the interlock of the machine.

If the interlock has been disabled then always return it to enable as soon as possible.

z Confirm that no current is flowing in the power cable (to be connected to the

machine) with a tester at the delivery, the installation, or the transfer of the

machine.

Note

Safe-34

Safety Precautions

0506-001
