Device Name Chip Mounter Block Name Page No. Unit Name Revision Model Item GXH-1 2.3.5 Master Nozzle Level Offset • Procedure for Teaching Operation (1) Use the master nozzle for which the placement and pickup heights ar…
Device
Name
Chip Mounter
Block Name
Page No.
Unit Name
Revision
Model ItemGXH-1
2.3.3 Teaching of Head Center/Basis Mark Position Offsets
Required Jig : Component Recognition Offset Jig JG-0085 (Standard Accessory Part)
Nozzle for Jig Pickup φ6 mm (Nozzle Type HA09)
After teaching the head center offset, be sure to perform a teaching operation on the basis
mark position offset.
• Procedure for Teaching Operation
(1) Put the jig on the jig depository.
(Left Front Side of Component Recognition Camera: Sides 1 and 4, Right Front Side:
Sides 2 and 3)
(2) Attach the vacuum nozzle to the Nozzle No. 1 position.
(3) Select one of the [1], [2], [3], and [4] buttons in the "Select head" group box of the
"HEAD CENTER/BASIS MARK POSITION OFFSET" window and confirm that "1" is
set in the "Nozzle No." text box in the "Designate Nozzle" group box. (Operation
Sequence: [MAINT.] Button → [TEACHING] Button → [OTHERS] Button → [HEAD
CNTR/MARK POS] Button)
(4) Select the [Teach Start (Hd center teach)] button and press the [START] button.
(5) After the teaching operation on the head rotational center, save the results.
(6) Perform a teaching operation on the basis mark position offset as follows.
Select the [Teach Start (Basis mark teach)] button and press the [START] button.
(7) Follow the same procedure for "[1] through [4]" in the "Select head" group box.
(8) Select the [End] button.
The "Confirmation to Saving" dialog box opens. Select the [Yes] button.
The teaching session is terminated.
2.3.4 Fly Recognition Camera Offset
(1) Select one of the [1], [2], [3], and [4] buttons in the "Select camera" group box of the
"FLY RECOG CAMR OFST" window. (Operation Sequence: [MAINT.] Button →
[TEACHING] Button → [OTHERS] Button → [FLY RECOG CAMR OFST] Button)
(2) Select the [Teach Start] button and press the [START] button.
(3) Select the [End] button.
The "Confirmation to Saving" dialog box opens. Select the [Yes] button.
The teaching session is terminated.
Heads
2. Installation Offset
1-12
0406-002
Device
Name
Chip Mounter
Block Name
Page No.
Unit Name
Revision
Model ItemGXH-1
2.3.5 Master Nozzle Level Offset
• Procedure for Teaching Operation
(1) Use the master nozzle for which the placement and pickup heights are measured.
Attach the master nozzle to the nozzle No. 1 position.
(2) Select one of the [1], [2], [3], and [4] buttons in the "Select head" group box of the
"MASTER NOZZLE LEVEL OFFSET" window and confirm that "1" is set in the
"Nozzle No." text box in the "Designate Nozzle" group box. (Operation Sequence:
[MAINT.] Button → [TEACHING] Button → [OTHERS] Button → [MA NOZ LVL
OFST] Button)
(3) Select the [Teach Start] button and press the [START] button.
Follow the same procedure for "[1] through [4]" in the "Select head" group box.
When it is checked if the linear measure sensor is dirty or not and the checking
results in "NG (No Good)", it is required to check how it is stained or nicked.
(4) Select the [End] button.
The "Confirmation to Saving" dialog box opens. Select the [Yes] button.
The teaching session is terminated.
• The offsets are entered in the "L (Height)" text boxes in the "Master Nozzle Level" tab
sheet. (Operation Sequence: [SUPV] Button → [EDIT] Button → [SYSTEM] Button
→ [EDIT] Button entitled "Machine System" → "Nozzle" Tab Sheet → "Master
Nozzle Level" Tab Sheet)
2.3.6 Nozzle Position Offset
• Procedure for Teaching Operation
(1) Enter and save the data to be used as the nozzle data.
Set the nozzle IDs to be used in the "Placement Head/Nozzle Data" window. (Operation
Sequence: [OPERATOR] Button → [SYSTEM] Button → [EDIT] Button entitled "
Placement Head/Nozzle" → "Nozzle Data" Button)
Be sure to check the dimensions in the nozzle type data.
(2) Attach the nozzles to be used.
(3) Select one of the [1], [2], [3], and [4] buttons in the "Select head" group box of the
"NOZZLE POSITION OFFSET" window and the [All nozzle] or the [Designate nozzle]
button. (Operation Sequence: [MAINT.] Button → [TEACHING] Button → [NOZ POS
OFFSET] Button)
(4) Select the [Teach Start] button and press the [START] button.
(5) Follow the same procedure for "[1] through [4]" in the "Select head" group box.
(6) Select the [End] button.
The "Confirmation to Saving" dialog box opens. Select the [Yes] button.
The teaching session is terminated.
• The target value is "0.2 mm or less".
Heads
2. Installation Offset
1-13
0403-001
Device
Name
Chip Mounter
Block Name
Page No.
Unit Name
Revision
Model ItemGXH-1
2.3.7 Nozzle Level Offset
This session describes how to teach the relative positional relation between the master nozzle and
the other nozzles.
• Procedure for Teaching Operation
(1) Attach the nozzles to be used.
(2) Select one of the [1], [2], [3], and [4] buttons in the "Select head" group box of the
"NOZZLE LEVEL OFFSET" window and the [All nozzle] or the [Designate nozzle]
button. (Operation Sequence: [MAINT.] Button → [TEACHING] Button → [NOZ LVL
OFFSET] Button)
(3) Select the [Teach Start] button and press the [START] button.
(4) Follow the same procedure for "[1] through [4]" in the "Select head" group box.
(5) Select the [End] button.
The "Confirmation to Saving" dialog box opens. Select the [Yes] button.
The teaching session is terminated.
Heads
2. Installation Offset
1-14
0403-001
