附录2 安全主要零件清单（List of safety critical Components）
电子零件装着机 SI-G200MK5(CS)
附 2-2
录
附
Parts Code Components Manufacturer Type & Model
Information of
Recognized,
listed
etc.
[MAIN POWER]
TB1
Terminal Block YOSHIDA ELECTRIC UK35-3J-SH2076 UL,CSA,TUV
[ELECTRICAL BLOCK]
TB2
Terminal Block YOSHIDA ELECTRIC
UK15-15J-SQ3064 UL,CSA,TUV
[POWER UNIT]
TB1
Circuit Breaker
IDEC BNH30W
UL,CSA,TUV
[DRIVER UNIT] TB1.2
[SERVO UNIT] TB1
Terminal Block
IDEC BNH15MW UL,CSA,TUV
[SERVO UNIT]
DRV-XF,XR
AC Servo Motor Driver
YASKAWA ELECTRIC CACR-5R5-SO4VAY108 UL,CSA,TUV
[SERVO UNIT]
DRV-YF,YR
AC Servo Motor Driver
YASKAWA ELECTRIC SGDV-120A21A UL,CSA,TUV
[SERVO UNIT]
DRV-HF,HR,RNF,RNR
AC Servo Motor Driver
YASKAWA ELECTRIC CACR-R90-SO4VAY108 UL,CSA,TUV
[SERVO UNIT]
DRV-FF,FR
AC Servo Motor Driver
YASKAWA ELECTRIC CACR-1R6-SO4VAY108 UL,CSA,TUV
[SERVO UNIT]
DRV-RTF,RTR
AC Servo Motor Driver
YASKAWA ELECTRIC CACR-2R8-SO4VAY108 UL,CSA,TUV
[INTELLIGENT CASSETTE
POWER UNIT] PS1
DC Power Supply TDK-Lambda HWS600-24 UL,CSA,TUV
FAN-F1,2,R1,2,3 AC FAN MINEBEA 4715MS-20T-B5A UL,CE
FAN-U1,2,3,4 AC FAN MINEBEA 3610PS-20T-B30 UL,CE
PRINTER
ADAPTER
AC Adapter
SEIKO Instruments PW-0904-W2-E UL,CSA,TUV
YF,YR,AXIS MOTOR AC SERVO Motor YASKAWA ELECTRIC
SGMAS-12ADA-SY11
UL,CSA,TUV
XF,XR,AXIS MOTOR AC SERVO Motor YASKAWA ELECTRIC SGMAV-06ADA21 UL,CSA,TUV
HF,HR,AXIS MOTOR AC SERVO Motor YASKAWA ELECTRIC SGMJV-01ADA21 UL,CSA,TUV
FF,FR,AXIS MOTOR AC SERVO Motor YASKAWA ELECTRIC SGMAV-C2ADA61 UL,CSA,TUV
RTF,RTR,AXIS MOTOR AC SERVO Motor YASKAWA ELECTRIC SGMAV-04ADA61 UL,CSA,TUV
RNF,RNR AXIS MOTOR AC SERVO Motor YASKAWA ELECTRIC SGMJV-01ADA61 UL,CSA,TUV
[I/O UNIT1]
Safety Control Board
Relay
Panasonic Electric Works SFS2-L-DC24V UL,CSA,TUV
FR EMG SW, other
Switch
Fuji Electric FA
Components & Systems
AH165-V5R02 UL,CSA,TUV
附录2 安全主要零件清单（List of safety critical Components）
电子零件装着机 SI-G200MK5(CS)
附 2-3
附录
Parts Code Components Manufacturer Type & Model
Information of
Recognized,
listed
etc.
DOOR F,R Switch OMRON D4NS-2DF UL,CSA,TUV
FRONT I/L SW
REAR I/L SW
Switch EAO
14-335.025K2 UL,CSA,TUV
[CART SWITCH]
SR30A,31A
Relay Unit OMRON
G9SX-NS202-RT
UL,CSA,TUV
[CART SWITCH]
SW30A,31A
Magnetic Switch OMRON
D40A-1C5 UL,CSA,TUV
[AREA SENSOR]
BS79,364
Beam Sensor OMRON E3ZS-T81A UL,CSA,TUV
RY1,2 Relay OMRON
G2R-2-SND DC24V
+ P2RF-08
UL,CSA,VDE
[DRIVER UNIT] CR1
[POWER UNIT] CR1
Relay
IDEC
RU4S-D-D24
+ SY4S-05B
UL,CSA,TUV
If more sheets are needed, copy this please.
Following components shall be listed here.
motor, transformer, relay, conductor (components which contains coils) etc.
switch, thermostats, heater, plug, capacitor, RFI-filter, fuse, breaker, etc.
