5.3 T raining Evaluation Circle the most appropriate answer from the list below. (1) The nozzle alignment adjustment should be performed at what angle? a. 180° b. 200° (2) The backlash for the nozzle changer gears should…
Notes:
Chapter 5 5.2 NC-Axis Adjustments
Edition 2.0 5-6 CP-7-series Level 3 Tutorial
5.3 Training Evaluation
Circle the most appropriate answer from the list below.
(1) The nozzle alignment adjustment should be performed at what angle?
a. 180°
b. 200°
(2) The backlash for the nozzle changer gears should be in the range:
a. 0.3 to 1.3 mm
b. 0.03 to 0.13 mm
(3) At what angle should the NC origin position be calculated?
a. 128°
b. 141°
(4) Which of the following would be the result of an incorrectly adjusted NC
origin position?
a. A station 15 error.
b. Low placing accuracy.
Chapter 5 5.3 Training Evaluation
Edition 2.0 5-7 CP-7-series Level 3 Tutorial
Notes:
Chapter 5 5.3 Training Evaluation
Edition 2.0 5-8 CP-7-series Level 3 Tutorial
