8.3 Training Evaluation
Circle the most appropriate answer from the list below.
(1) Under which of the following circumstances would the parts cameras
need adjusted.
a. After lens replecement
b. After replacement of the X-motor.
(2) What should be the Gain setting on the amplifier for both cameras?
a. A
b. M
(3) What is the apperture setting for the wide camera?
a. 2
b. 2.8
(4) At what angle is the camera focus adjustment performed?
a. 180°
b. 200°
(5) What should be the distance between the camera lens cover and the
prism surface?
a. 5 mm
b. 0.5 mm
(6) What would be the result of a scewed camera?
a. Vision processing error.
b. Parts placed skewed on the board.
