Chapter 1 1.7 T raining Evaluation Edition 2.0 1-30 CP-7-series Level 3 T utorial Notes:
Chapter 1 1.7 Training Evaluation
Edition 2.0 1-29 CP-7-series Level 3 Tutorial
1.7 Training Evaluation
Circle the most appropriate answer from the list below.
(1) X-motor Proper data adjsutment should be performed after:
a. Replacing the X-motor
b. Performing parts camera adjustments.
(2) The + OT sensor should be removed prior to performing X-axis Proper
data adjustments.
a. True
b. False
(3) The -OT sensor on the X-axis should activate at the position:
a. 2000 pulses back from the + mechanical stopper.
b. 500 pulses back from the + mechanical stopper.
(4) When performing Proper data adjustments on the Y-motor:
a. Both sides of the coupling should be loosened.
b. Only the motor side should be loosened.
(5) When performing -OT adjustments on the Y-axis, is it necessary to adjust
the position of the dog or the sensor itself?
a. Dog
b. Sensor
(6) When adjusting the position of the (+) mechanical stopper on the Z-axis,
always ensure that:
a. The out carrier is in the retract position.
b. The out carrier is in the advance position
(7) What is the significance of middle loading position?
a. This is the position which the Z-axis lowers to when the XY-table
moves from out loading position to loading position.
b. This is the height of the Z-axis during placement.
(8) What is the purpose of the MOT sensor?
a. To limit the height of the XY-table during placement?
b. To limit the height of the XY-table while in loading
position.
Chapter 1 1.7 Training Evaluation
Edition 2.0 1-30 CP-7-series Level 3 Tutorial
Notes:
Chapter 2
X, Y, and Z-Axes
Calibration Data
Measurements
Objective:
Given a CP-7-series machine, technical
documentation and required tools,
perform X, Y, and Z-axes calibration
data adjustments to FUJI specifications.
