6. Set the pickup height jig to zero, and remove the stopper bracket. Then
slot the jig onto the device table (slot no. 23) and install the nozzle jig on
the nozzle holder (no. 1).
7. Rotate the cam axis to 170°, ensuring that the needle of the pickup height
jig is directly below the nozzle jig.
8. Manually move the NZ-axis until the dial gauge reads zero (at this point
there should be a space of 0.65 mm between the tip of the nozzle and the
feeder). Take note of the motor pulse count at this point.
9. Repeat the procedure for all 16 heads. Take the average value of the 16
heads and set this as the NZ origin position in the machine’s calibration
data using the following commands:
[MAINTENANCE] → [CALIBRATION] → [PICKUP REFERENCE] →
[NZ ORIGIN POSITION].
CP-732E Calibration Data Servo Count Chart (NZ-axis)
Caution
Ensure that new Calibration data is backed-up to the host computer
once the adjustment procedure is complete.
CN002
Plus mechanical stopper
Max limit pos.NZ
Pickup Pos. NZ
Min limit pos. NZ
Minus mechanical stopper
12770 ± 500
12670 ± 500
4000 ± 1000
100 ± 50
0 ± 50
CP7T36005
Chapter 6 6.2 NZ-Axis Adjustments
Edition 2.0 6-6 CP-7-series Level 3 Tutorial
6.3 Training Evaluation
Circle the most appropriate answer from the list below.
(1) The NZ-motor is required for offsetting placing height for those parts
such as 0603s that require high accuracy.
a. False
b. True
(2) Failure if the NZ-axis may result in which of the following.
a. Damaged nozzles
b. Miss-picks of smaller components
(3) The NZ motor coupling should be tightened with the motor pulse count
at:
a. 200 pulses
b. 0 pulses
(4) Pickup height adjustment should be performed at what angle?
a. 180°
b. 170°
(5) Which of the following should be used for the nozzle origin position?
a. The average result for all 16 heads
b. The results obtained using Head A
Chapter 6 6.3 Training Evaluation
Edition 2.0 6-7 CP-7-series Level 3 Tutorial
