Notes: Chapter 7 7.3 T raining Evaluation Edition 2.0 7-8 CP-7-series Level 3 T utorial
7.3 Training Evaluation
Circle the most approproate answer from the list below.
(1) Under which of the following circumstances would the fiducual camera
need to be adjusted?
a. After replacing the X-motor
b. After replacing the Z-motor
(2) XcYc is the position that the table moves to in order to read a fiducial
mark.
a. True
b. False
(3) The select switch at the rear of the amplifier should be set to:
a. 1/30N
b. 1/60N
(4) What is the power supply required for the fiducial camera?
a. 12VDC
b. 24VDC
(5) What should be adjusted if the resluts for camera resolution lie outwith
the specified range?
a. The camera height.
b. The camera gain.
Chapter 7 7.3 Training Evaluation
Edition 2.0 7-7 CP-7-series Level 3 Tutorial
Notes:
Chapter 7 7.3 Training Evaluation
Edition 2.0 7-8 CP-7-series Level 3 Tutorial
Chapter 8
Parts Cameras
Objective:
Given a CP-7-series machine,
technical documentation and
required tools, remove, replace and
calibrate the Wide and Narrow
cameras to FUJI specifications.
