CP-7-series Level 3 Tutorial Manual Edition 1.0 October 1, 2000 Edition 2.0 June 1, 2001 FUJI Machine Manufacturing Co., Ltd. SMT Equipment 19 Chausuyama, Yamamachi, Chiryu, Aichi Prefecture, 472-8686 Japan Copyright  2…

100%1 / 158
[Minimum]
0deg 90deg 180deg 270deg
No X Y Ang X Y Ang X Y Ang X Y Ang
A 148 -63 -3 -32 -179 -216 -176 -11 76 11 146 131
B 79 55 117 67 -154 -141 -127 -114 119 -118 64 14
C 138 13 203 27 -187 -217 -180 -78 174 -51 148 -115
D 175 -50 -693 -39 -223 -28 -208 0 112 15 185 69
E 156 -28 372 -18 -199 44 -180 -22 133 -3 156 -91
F 139 -84 -20 -90 -173 26 -154 34 102 51 129 65
G 173 -34 -165 -25 -189 206 -176 -32 -248 -9 138 -534
H 67 -14 -357 -11 -105 -417 -108 -46 -198 -46 64 47
I 86 -58 -19 -52 -96 -230 -102 19 327 30 75 -302
J 174 -34 -149 -8 -208 -50 -186 -23 -25 0 167 -284
K 212 20 -212 17 -228 -134 -218 -64 17 -58 194 -19
L 122 -16 -157 -14 -156 -88 -141 -26 -171 -14 120 -169
M 131 -25 -236 -32 -157 34 -133 -13 5 -5 114 -577
N 83 -33 -404 -31 -115 -342 -100 -21 -600 3 68 -411
O 131 -10 215 -4 -144 -233 -159 -25 -10 -14 114 -196
P 108 -69 129 -58 -171 148 -165 22 135 32 117 55
[Average by nozzle]
No X Y Ang
A 5 -6 157
B 5 -4 326
C -2 -5 236
D 5 -7 282
E 3 -6 335
F 5 -5 297
G 8 -9 88
H -4 -5 117
I 5 0 165
J 5 -6 86
K 4 -7 172
L 9 -1 94
M 4 -7 68
N 4 -7 27
O 7 -3 265
P 2 -6 277
Data below this point omitted
Chapter 9 9.1 PAM
Edition 2.0 9-15 CP-7-series Level 3 Tutorial
Notes:
Chapter 9 9.1 PAM
Edition 2.0 9-16 CP-7-series Level 3 Tutorial
