After selecting the Edit function the following Edit screen is displayed:

— Here, the parameters can be modified locally.

— The values for acceleration and deceleration can not be edited.

— The maximum possible value of the speed is taken from the machine data.

— The value range for the force is from 1 to 99.

— For the start and end positions only values within the traversing range, as entered in the machine data,

are possible.

•

Description of the Functional Sequences

—

EDIT: The values are changed in the editor of the continuous run function only temporarily. The origi-

nal MA data entries in the machine data remain unchanged. The AutoCal program uses the default va-

lues for all remaining functions.

—

POSIT.: The selected start position is approached on the basis of the selected parameters.

—

CONT. OP.: When this function is selected, the "START" label in the function key is replaced by

"STOP". The text labels of the other keys are deleted. All axes are made to travel back and forth be-

tween the two positions INITIAL POSITION and FINAL POSITION. Also here the selected parameters

are used. After every traversing operation a defined time span of 0.5 ms elapses which is fixed pro-

grammed in the software. Pressing the STOP button causes the continuous run to be terminated.

—

CONTINUOUS OPERATION WITH STAND STILL CHECK (only Z-axis): Here, the Z-axis travels in

downward direction by means of standstill control and deposits the steel nozzle on the previously loa-

ded PCB. Depositing the nozzle is to be confirmed by pressing <RETURN>. The continuous run with

standstill control starts and can be terminated at any time by pressing "STOP". After the termination,

the head always moves to the 0-count position.

SIEMENS CALIBRATION PROGRAM AutoCal 114.xxx

STATION 1 ---------------------------------------------------------------------------------------------------------------------

-------------------------- 0

SPEED 1 [in m/s^2]

ACCELERATION 10 [in m/s^2]

DECELERATION 10

POWER 8

-------------------------- 0

INITIAL POSITION 0 (>Z_min) [digit]

FINAL POSITION 1000 (<Z_max) [digit]

-------------------------------------------------------------------------------------------------------------------------------------------

MOVE WITH CURSOR KEYS ( ^, v, PREV, NEXT) SELECT WITH <RETURN> KEY

END

5 Description of the Menu Options User’s Manual AutoCal Program

5.1 Description of the Menu Options for HS-180 Placement Stations Software Version 114.xxx

5 - 10

5.1.21 I/O MENU

This menu permits you to set the desired outputs by selecting "TEST OUTPUTS", to toggle the outputs by se-

lecting "Endurance run" and to check the updated inputs in each case on the screen. Selecting "TEST IN-

PUTS" causes all signal state changes of the inputs to be displayed on the screen in an additive process.

WARNING

∆

!

∆

!

Any

concurrent setting

of competing outputs may result in

damage to the machine!

N o (!)

verification by the software is carried out !

•

TEST OUTPUTS

After selecting the "TEST OUTPUTS" function the screen for the inputs and outputs is displayed (see next

page).

—

The signal state of the inputs is continuously monitored and updated on the screen.

Signal state 1 is indicated on the screen by the character enclosed in parentheses.

— At the start, all outputs are set to "ZERO". Using the cursor keys you can move around in the matrix

displayed and select the output. The cursor is identified by the character. Active outputs are marked -

just as the inputs - by the character.

Pay attention to the WARNING, above:

It is possible that several outputs are set simultaneously!

— To "toggle" (signal state change from 1 to 0 or from 0 to 1) the selected output, press the RETURN

key.

— If you actuate "CONT. OP. START" (function key F1) the output identified by the character is

toggled.

SIEMENS CALIBRATION PROGRAM AutoCal 114.xxx

STATION 1 -----------------------------------------------------------------------------------------------------------------------

I/O MENU

TEST INPUTS

TEST OUTPUTS

-------------------------------------------------------------------------------------------------------------------------------------------

MOVE WITH CURSOR KEYS ( ^, v, PREV, NEXT)

SELECT WITH <RETURN> KEY

END

User’s Manual AutoCal Program 5 Description of the Menu Options

Software Version 114.xxx 5.1 Description of the Menu Options for HS-180 Placement Stations

5 - 11

The inputs are also updated on the screen during the continuous run. Each input is checked

8 times before the output is changed again.

After selecting the continuous run, the label of function key F1 is changed to "CONT. OP. STOP".

Any change of the other outputs is no longer possible.

— The continuous run is terminated by pressing function key f1 once more.

— Actuating the "RESET" key causes all outputs to be set to zero. The "RESET" key is not active during

the continuous run.

Screen display after selecting "TEST OUTPUTS":

SIEMENS CALIBRATION PROGRAM AutoCal 114.xxx

STATION 1 ----------------------------------------------------------------------------------------------------------------------

INPUTS OUTPUTS

Bit 0 1 2 3 4 5 6 7 Bit 0 1 2 3 4 5 6 7

EF820 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) AF800 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )

EF821 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) AF801 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )

EF822 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) AF802 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )

EF823 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) AF803 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )

EF824 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) AF804 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )

EF825 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) AF805 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )

EF826 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) AF806 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )

EF827 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( ) AF807 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )

AF808 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )

AF809 ( ) ( ) ( ) ( ) ( ) ( ) ( ) ( )

ATTENTION! SETTING COMPETING OUTPUTS SIMULTANEOUSLY MAY RESULT DAMAGE!

TO CHANGE AN OUTPUT, PRESS <Return>

➤ When setting outputs, pay attention to the WARNING on page 11!

CONT. OP.

START

RESET

END

5 Description of the Menu Options User’s Manual AutoCal Program

5.1 Description of the Menu Options for HS-180 Placement Stations Software Version 114.xxx

5 - 12
