Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.18 VACUUM DEVICE
Version
01
Title
检查SOLENOIDE VALVE
Page
3-18-18
Note
[检查 SOLENOIDE VALVE]
检查连接到 Solenoid Valve 的配件
再组装连接到 Solenoid Valve 的配件
检查连接到 Solenoid Valve 的气动软管
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.19 ELECTRIC DEVICE
Total Pages
31
目录
[组装 FRONT POWER PANEL SUB] ................................................................... 2
[组装 REAR POWER PANEL SUB] ..................................................................... 4
[MAIN 电源 SHORT TEST] .................................................................................. 6
[DC 电源 SHORT CHECK] ................................................................................. 11
[电压 CHECK TEST] .......................................................................................... 12
[变更设备电源 AC380V] ..................................................................................... 23
[测定接地电阻] ................................................................................................... 24
[更换电源] .......................................................................................................... 25
[组装 MOTOR DRIVER] ..................................................................................... 27
[SMEMA 检查].................................................................................................... 29
[组装其他安装品] ................................................................................................ 30
[再连接 MOTOR DRIVER CABLE] .................................................................... 31
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.19 ELECTRIC DEVICE
Version
01
Title
组装FRONT POWER PANEL SUB
Page
3-19-2
Note
[组装 FRONT POWER PANEL SUB]
1. 注意开关方向，Panel 上组装 Load Switch
2. 固定组装于 Panel 的 Load Switch
3. Panel 上插入 Safeguard Override key
4. 用开关组装夹具固定后，组装 Safeguard Override key
5. 将 Key 固定于电缆
