Model DECAN Series Company SAMSUNG TECHWIN Module 3.3 BUT T otal Pages 4 目录 [ 检查 BUT 启动 ] ................................................................................................... 2 [ 更换 BUT 感应器 ] .............…
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.2 BOARD
Version
01
Title
更换CONVEYOR SUB IF BOARD
Page
3-2-34
Note
[更换 CONVEYOR SUB IF BOARD]
Conveyor Sub IF Board用于将OP Panel的状态传送到CAN Conveyor Board和Safety Frop Board，将
气动Sensor的数字输出值传送到CAN Conveyor
1. 拆卸连接到电路板的电缆
2. 松开固定电路板的固定螺栓，更换新电路板
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.3 BUT
Total Pages
4
目录
[检查 BUT 启动] ................................................................................................... 2
[更换 BUT 感应器] ................................................................................................ 3
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
3.3 BUT
Version
01
Title
检查BUT启动
Page
3-3-2
Note
[检查 BUT 启动]
1. 在 MMI 的<Diagnosis><IO>菜单，检查<BUT I/O>启动状态
2. 检查 Backup Table 外观上撕痕、压痕等损坏状况
3. 检查 Backup Table Up/Down Sol.valve 的 Speed Control 是否关闭
* 检查点
- Backup Table外观上不应有撕痕、压痕
- Backup Table Up/Down Sol.valve的Speed Control应关闭
