Model DECAN Series Company SAMSUNG TECHWIN Module 3.5 CONVEYOR V ersion 01 Tit le 检查传输带张力 Page 3-5-2 Note [ 检查传输带张力 ] * 张力测定位置 * PCB 移送带张力设定标准分类 Entrance Wor k Exit PCB 移送带 160±10Hz 40±5Hz 160±10Hz 宽度调节带 22±2Hz 350±20Hz…

Model

DECAN Series

Company

SAMSUNG TECHWIN

Module

3.5 CONVEYOR

Total Pages

[检查传输带张力] .................................................................................................. 2

[传输带、ANC 高度标准] ...................................................................................... 3

[CONVEYOR PCB GUIDE 高度标准] .................................................................. 4

[变更传输带方向(MMI)] ........................................................................................ 5

[变更传输带选项(MMI)] ........................................................................................ 8

[检查 EDGE FIXER 启动] ................................................................................... 10

[检查 EDGE FIXER 连接状态] ............................................................................ 11

[设定 LONG CONVEYOR 选项(MMI)] ................................................................ 12

[检查 SHUTTLE 部连接状态] .............................................................................. 14

[SINGLE-CONVEYOR 选项时模块组装位置] ..................................................... 18

[宽度调节电机 Z 上 SETTING] ........................................................................... 19

[更换电机] .......................................................................................................... 21

[LEAD SCREW & LM GUIDE 清洁及加油] ......................................................... 28

[更换传感器] ....................................................................................................... 29

[更换 STOPPER CYLINDER] ............................................................................ 30

[检查 FIDUCIAL MARK] ..................................................................................... 31

Model

DECAN Series

Company

SAMSUNG TECHWIN

Module

3.5 CONVEYOR

Version

Title

检查传输带张力

Page

3-5-2

Note

[检查传输带张力]

* 张力测定位置

* PCB移送带张力设定标准

分类

Entrance Work Exit

PCB移送带

160±10Hz 40±5Hz 160±10Hz

宽度调节带

22±2Hz 350±20Hz 22±2Hz

SYNC带

- 22±2.5Hz -

* 传输带张力调整方法

PCB移送带宽度调节带

用调节Idler，调整Belt Work的张力用Tension Bracket调整Belt Width Sync Tension

Model

DECAN Series

Company

SAMSUNG TECHWIN

Module

3.5 CONVEYOR

Version

Title

传输带、ANC高度标准

Page

3-5-3

Note

[传输带、ANC 高度标准]

 传输带

 工具：Height gauge (最小刻度：2um)

 标准：-0.1 ~ 0.1 mm

 ANC

 工具：Height gauge (最小刻度：2um)

 标准：-0.05 ~ 0.05 mm
