I･pulse F1 Series
F1-44 (E type)
P 6
No. Code No. Parts Name Q'ty Parts No.
LG4-M8A60-011 BACK PLATE ASSY 1 AS3-A24-8150-D
1 K87-M2387-000 PLANE WASHER 2 CTF- 54- 66-1
2 KW1-M458E-000 RING SCREW 2 CTF-A12- 566-1
3 K87-M538C-000 POSITION PLATE 1 CTF-A32- 49-2
4 LG4-M1A72-000 CONNECT PIN 1 FTA-A08-8146
5 LG4-M8A63-011 ROLLER SHAFT 1 FTA-A44-8132-D
6 LG4-M8A64-000 SHAFT 1 FTA-A44-8140
7 LG4-M6A71-000 ROD CONNECTER 1 FTA-A24-8142
8 LG4-M6A73-001 ADJUST PLATE 1 FTA-A24-8148-C
9 LG4-M6A74-000 CYLINDER BRACKET 1 FTA-A24-8149-B
10 LG4-M6A61-011 BACK PLATE 1 FTA-A24-8150-D
11 LG4-M7A62-010 REEL SHAFT 1 FTA-A32-8151-B
12 LG4-M6AB1-000 VAL PACK CYLINDER 1 FTA-A24-8157
13 LG4-M8A6A-010 GUIDE PLATE 1 FTA-A44-8177-B
14 K87-M56C1-000 BARB CONNECTOR 1 BF4BU
15 K87-M111N-000 SCREW,PAN HEAD+ 2 3MC-3-P
16 K87-M111S-000 SCREW,FLAT HEAD+ 2 3MK-6-P
17 LG4-M4ADE-000 SCREW,FLAT HEAD+ 2 3MK-7-P
18 K87-M55BN-000 SCREW,FLAT HEAD+ 1 3MK-8-P
19 KW1-M45BG-000 SCREW,FLAT HEAD+ 1 3MK-10-P
20 K87-M11B4-100 SCREW,FLAT HEAD+ 4 3MK-12-P
21 LG4-M6ADJ-000 SCREW,FLAT HEAD LEFT 1 4MK-8-P-L
22 LG4-M6ADE-000 SCREW,FLAT HEAD+ 2 4MK-10-P
23 KW1-M111T-000 SCREW,THIN HEAD 1 TH-TP-HS-M3-5
24 K87-M21BN-000 SCREW NUT 1 3MH-P
25 K87-M11D7-000 CIRCLIP E 1 E.32
26 KW1-M458F-000 DOUBLE RING 2 コクヨ リン-17
27
28
29
30
I･pulse F1 Series
F1-44 (E type)
P 7
No. Code No. Parts Name Q'ty Parts No.
1 LG4-M6A1A-000 MICRO SWITCH BRACKET 1 FTA-A24-8135-B
2 LG4-M8A6B-000 C.B.COVER 1 FTA-A44-8137
3 LG4-M6A6C-000 COVER 1 FTA-A24-8138-B
4 LG4-M6A6D-000 LED,SWITCH COVER 1 FTA-A24-8139-B
5 LG4-M6AA1-001 CONTROL BOARD 1
FTA-A24-8153-FCN1
6 LG4-M6AA2-000 CONTROL BOARD 1 FTA-A24-8154
7 LG4-M6AA4-000 VALVE HARNESS ASSY 1 FTA-A24-8155
8 LG4-M6AA3-000 MICRO SWITCH ASSY 1 FTA-A24-8156
9 K87-M534F-000 SCREW,TRUSS HEAD+ 1 T3M-4-P
10 K87-M23BL-000 SCREW,TRUSS HEAD+ 2 T3M-5-P
11 K87-M111N-000 SCREW,PAN HEAD+ 6 3MC-3-P
12 K87-M111W-000 SCREW,PAN HEAD+ 5 3MC-5-P
13 LG4-M1ADC-000 SCREW,PAN HEAD+ 3 3MC-7-P
14 LG4-M6ADG-000 BOLT,HEX SOCKET HEAD 2 3MX-5-P
15 K87-M11BE-000 THRUST WASHER 6 3MV (3V-0.5-8-P)
16 LG4-M7AC2-000 SET UP STICKER 1 FTA-A32-8137-SPS
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
