2F-13
I･pulse F1 Series
F1-82-1005 (F type)
P 7
No. Code No. Parts Name Q'ty Parts No.
LG4-M1A90-000
REEL HOLDER ASSY
1
AS -201720
1 LG4-M1AA1-002 CONTROL BOARD 1
FTA-A08-8151-FCB
2
LG4-M1A6R-010
CONTROL BOARD COLLAR 3
FTA-A08-8152-B
3
LG4-M2A6S-000
CONTROL BOARD COVER
1
FTA-A08-8153-B05
4
LG4-M1A91-000
REEL HOLDER
1
201720
5 LG4-M1A92-000
CLAMP ARM
1
201721
6 K87-M111N-000 SCREW,PAN HEAD+ 3
3MC-3-P
7 K87-M111W-000 SCREW,PAN HEAD+ 3
3MC-5-P
8 LG4-M1ADF-000
SCREW,BAIND HEAD+
3
3M-10-P-P-Bi
9
LG4-M1AC1-000 SERIAL NO. STICKER 1
FTA-A08-8150-SNS
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
