3F- 11
I･pulse F1 Series
F1-84 (F type)
P 5
No. Code No. Parts Name Q'ty Parts No.
※1 LG4-M1A60-120 BACK PLATE ASSY 1 AS2-A08-8250
1 K87-M116A-100 SPRING HOOK PIN 4 CTF-M08- 166-B
2 KW1-M116U-000 ROLLER 2 CTF-M08- 342
3 LG4-M1A72-000 CONNECT PIN 1 FTA-A08-8146
4 LG4-M1A71-000 ROD CONNECT 1 FTA-A08-8147
5 LG4-M1A61-100 BACK PLATE 1 FTA-A08-8250
6 LG4-M1AA3-000 MICRO SWITCH ASSY 1 FTA-A08-8151-6
7 LG4-M1AA4-000 VALVE HARNESS ASSY 1 FTA-A08-8151-7
8 LG4-M1A6A-000 ROLLER AXIS T 1 FTA-A08-8173
9 LG4-M1A6C-000 LEAF T 1 FTA-A08-8173-1
10 LG4-M1A6B-000 ROLLER AXIS U 1 FTA-A08-8174
11 LG4-M1A6D-000 LEAF U 1 FTA-A08-8174-1
12 LG4-M1A6N-000 MIDDLE GUIDE PLATE C 1 FTA-A08-8176-C
13 LG4-M1AB1-001 VAL PACK CYLINDER 1 BDA10×15-350W
14 LG4-M1AB3-000 BARB CONNECTOR 1 BF3BU-136W
15 K87-M111N-000 SCREW,PAN HEAD+ 3 3MC-3-P
16 LG4-M1ADC-000 SCREW,PAN HEAD+ 1 3MC-7-P
17 K87-M11B4-100 SCREW,FLAT HEAD+ 2 3MK-12-P
18 LG4-M1ADD-000 SCREW,FLAT HEAD+ 4 3MK-14-P
19 K87-M21BN-000 SCREW,NUT 2 3MH-P
20 K87-M11D7-000 CIRCLIP E 1 E.32
21
22
23
24
25
26
27
28
29
30
※1…F1-84-36756F～
3F-10
3F-11
I･pulse F1 Series
F1-84 (F type)
P 6
No. Code No. Parts Name Q'ty Parts No.
LG4-M1A87-000 TENSION LEVER ASSY 1 AS -A08-8160-B
LG4-M1A8E-000 IDLER ROLLER ASSY 1 AS -A08-8162
LG4-M1A86-000 I．ROLLER ALL ASSY 1 AS1-A08-8162
LG4-M1A82-012 INDEKING LEVER ASSY 1 AS3-A08-8164
LG4-M1A8D-000 DRIVE ROLLER ASSY 1 AS -A08-8170
LG4-M1A81-003 D．ROLLER ALL ASSY 1 AS1-A08-8170
1 K87-M111C-000 PLANE WASHER 1 CTF-A08- 16-B
2 K87-M117B-000 PLANE WASHER 2 CTF-M08- 76-B
3 KW1-M11A3-001 LOWER GUIDE PLATE,L 1 FTA-A08-1179-C
4 LG4-M1A62-000 METAL SHAFT 1 FTA-A08-8155
5 LG4-M1A8C-000 LEVER METAL 1 FTA-A08-8158-B
※1 6 LG4-M1A63-500 LEVER AXIS PIN 1 FTA-E08-8559
※1 7 LG4-M1A64-500 WASHER 1 FTA-E08-8559-1
8 LG4-M1A65-010 TENSION LEVER 1 FTA-A08-8160-B
9 LG4-M4A8B-000 TENSION LEVER RE. SP. 1 FTA-A12-8160-700
10 LG4-M1A66-010 ROLLER AXIS 1 FTA-A08-8163-B
11 LG4-M1A83-000 INDEKING LEVER 1 FTA-A08-8164
12 LG4-M1A8A-000 INDEKING LEVER RE. SP. 1 FTA-A08-8164-440
13 LG4-M1A84-010 ARM STUD 1 FTA-A08-8166-B
14 LG4-M1A85-000 ROLLER 1 FTA-A08-8167
15 LG4-M1A6M-000 MIDDLE GUIDE PLATE T 1 FTA-A08-8177-C
16 LG4-M1A6P-011 LOWER GUIDE PLATE,R 1 FTA-A08-8178-C
17 K87-M11BF-000 SCREW,FLAT HEAD+ 1 P2MK-4-IB
18 K87-M11BB-000 SCREW,FLAT HEAD+ 2 P2.6MK-5-IB
※1 19 K87-M111W-000 SCREW,PAN HEAD+ 1 3MC-5-P
20 K87-M111N-000 SCREW,PAN HEAD+ 6 3MC-3-P
21 K87-M11BE-000 THRUST WASHER 4 3V-0.5-8-P
22
23
24
25
26
27
28
※1…F1-84-36756F～
