5-3
I･pulse F1 Series
F1-16(C type)
No. Code No. Parts Name Q'ty Parts No.
LG4-M5A10-001 Body Assy
1
AS-A16-8101
LG4-M4A1M-000 Main Lever Assy
1
AS-A12-8131
1 K87-M111G-100 Push Pin 1
CTF-M08- 325
2
LG4-M1A1L-000 Thrust Washer
1
CTF- 53- 38-02
3 K87-M111H-200 Back Stopper 1
FTA-A08-1114
4
LG4-M4A1T-000
Arm Axis Pin 1 FTA-A12-8134
5
LG4-M5A11-001
Body 1
FTA-A16-8101
6
LG4-M1A12-000
Main Guide Pin 1
FTA-A08-8102
7
LG4-M1A13-000 Locate Pin R
1
FTA-A08-8103-B
8
LG4-M1A14-000 Locate Pin F
1
FTA-A08-8104-B
9
LG4-M4A15-000
Plug Holder Guide Ring
1
FTA-A12-8105
10
LG4-M1A16-000 Plug Holder
1
FTA-A08-8106
11
KW1-M221F-100 Stopper Pin
1
CTF-M12- 313
LG4-M4A19-000 Back Stopper Return Spring
1
FTA-A12-8114-600
LG4-M4A19-001 Back Stopper Return Spring
1
FTA-A08-6164-1600
13
K87-M211B-000 Back Stopper Axis
1
CTF-M12- 315
14
LG4-M1A1K-000 Lever Axis Pin
1
FTA-A08-8130-B
15
LG4-M4A1N-000 Main Lever
1
FTA-A12-8131
16
LG4-M4A1P -000 Arm
1
FTA-A12-8135-B
17
KW1-M224E-000
Arm Axis Pin 1
FTA-A12-1134
18 K87-M56C1-000
Barb Connector
1
BF4BU
19
LG4-M1AB2-000 Plug
1
MA-MC05PM
20
LG4-M4ABA-001 Air Hose
1
U4B-167
21 K87-M23B3-000 Screw , Set
(クボミ先) 3
3MY-5
22 K87-M111R-000 Screw , Set 6
3MY-5-F
23
K87-M1115-000 Circular Rivet
1
φ2-10
24
LG4-M1AD2-000 Circlip C
1
STW-7
25
26
27
28
29
30
31
LG4-M4A19-000 (～F1-16-000794C）
LG4-M4A19-001 (F1-16-000795C～）
12※
※
5-2
5-3
I･pulse F1 Series
F1-16(C type)
No. Code No. Parts Name Q'ty Parts No.
KW1-M1120-000 SPROCKET ASSY 1 AS2-A08-1107-P4
LG4-M4A2A-000
RACKING LEVER ASSY 1 AS-A12-8117
LG4-M4A2M-000 RATCHET AXIS ASSY
1
AS-A12-8112
1 K87-M111C-000 PLANE WASHER 1
CTF-A08- 16-B
2
LG4-M4A2E-000
RACKING LEVER 1
FTA-A12-8108
3 K87-M112F-000 SPRING HOOK PIN 1
CTF-A08- 211-B2
4 K87-M112M-100 FLANGE A 1
CTF-A08- 712-1
5 KW1-M452D-000 SCREW COIL SPRING 1
CTF-M08- 511-1
6 K87-M1121-000 METAL 1
FTA-A08-1103
7 K87-M1122-000 RIVET 3
FTA-A08-1103-1
8 KW1-M1123-000 SPROCKET 1
FTA-A08-1104-B
9 K87-M1124-000 RATCHET 1
FTA-A08-1107-P4
10 K87-M112G-100 RACKING POLE 1
FTA-A08-1111
11
LG4-M1A2D-000 SHUTTER DRIVE PIN
1
FTA-A08-8109
12
LG4-M1A2C-000 RACKING POLE AXIS
1
FTA-A08-8110
13
LG4-M4A2N-000 RATCHET AXIS
1
FTA-A12-8112
14
LG4-M4A2P-000 FLANGE B
1
FTA-A12-8112-2
15
LG4-M4A2B-000 MAIN ARM
1
FTA-A12-8117
16
LG4-M4A1R-000 SUB ARM
1
FTA-A12-8138
17 K87-M11BF-000
SCREW , FLAT HEAD
1
P2MK-4-IB
18
19
20
21
22
23
24
25
26
27
28
29
30
31
