9-9
I･pulse F1 Series
F1 - 56 (A type) 56mm
No. Code No. Parts Name Q'ty Parts No.
LG4-M9A40-000
TAPE GUIDE PLATE ASSY 1 AS-A56-8119-B
1
LG4-M7A46-000
LOCK LEVER 1
FTA-A32-8127
2
LG4-M1A48-000
TAPE GUIDE PUSH SPRING 1
FTA-A08-8127-500
3
LG4-M1A4K-000
T.G.A. GUIDE PIN 1
FTA-A08-8129
4
LG4-M7A43-000
SHUTTER PIECE 1
FTA-A32-8120-1
5 KW1-M4548-000 RIVET 2
FTA-A24-1120-2
6 KW1-M4549-000 SHUTTER GUIDE 1
FTA-A24-1120-3
7 KW1-M4544-000 SHUTTER GUIDE PIN 2
FTA-A24-1122-B
8
LG4-M9A41-000
TAPE GUIDE PLATE 1
FTA-A56-8119-B
9
LG4-M9A42-000
SHUTTER PLATE 1
FTA-A56-8120
10
LG4-M6A49-000
COVER PLATE 1
FTA-A24-8123
11
LG4-M6A4L-000
TAPE GUIDE AXIS PIN 2
FTA-A24-8124
12
LG4-M6A47-000
T.G. GUIDE PIN 1
FTA-A24-8125
13 K87-M1547-000 SCREW,TRUSS HEAD 2 T2M-2.5-P
14 K87-M1548-000 PLANE WASHER 2 2MV(2V-0.4-6-P)
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
9-8
9-9
I･pulse F1 Series
F1 - 56 (A type) 56mm
No. Code No. Parts Name Q'ty Parts No.
LG4-M6A80-000
INDENTATION LEVER ASSY 1
AS-A24-8159
LG4-M6A8A-000
SUB LEVER ASSY 1 AS-A24-8160
LG4-M7A84-000
REEL SHAFT ASSY 1 AS-A32-8152
KW1-M759N-000 METAL ASSY 1 AS -A56-1153-D
1 K87-M119J-000 THRUST WASHER 3 CTF- 42- 60-L
2 K87-M111C-000 PLANE WASHER 1 CTF-A08- 16-B
3 KW1-M459P-000 METAL PIN 2 CTF-A12- 653-1
4 K87-M459Y-000 PLANE WASHER 1 CTF-A12- 656
5 K87-M539M-000 SPRING 1 CTF-A32- 64-2
6 KW1-M559T-000 METAL 1 FTA-A56-1153-D
7 KW1-M459V-000 REEL FLANGE 1 FTA-A24-1154-D
8 KW1-M559U-000 REEL PLATE 1 FTA-A56-1155-E
9
LG4-M6A8E-000
SUB ARM 1 FTA-A24-8146-B
10
LG4-M7A85-000
REEL SHAFT 1 FTA-A32-8152
11
LG4-M6A8D-000
ARM STUD 1 FTA-A24-8158
12
LG4-M6A81-000
INDENTATION LEVER 1 FTA-A24-8159
13
LG4-M6A8B-000
SUB LEVER 1 FTA-A24-8160
14
LG4-M6A2C-000
SHUTTER DRIVE PIN 1
FTA-A24-8116-1
15
LG4-M6A8G-000
INDEX GEAR 1 FTA-A24-8161
16
LG4-M6A83-000
DRIVE GEAR 1 FTA-A24-8162
17
LG4-M6A82-000
GEAR AXIS 1 FTA-A24-8163
18 K87-M219E-100 ONE-WAY CRUTCH 1 FC-6
19 KW1-M119B-000 ONE-WAY CRUTCH 1 OWC4-13-3.1-L
20 K87-M5596-000 OILLESS BEARING 1 80B-0808
21 KW1-M459R-000 MAGNET 2 φ6-3
22 K87-M11BF-000 SCREW,FLAT HEAD 1 P2MK-4-IB
23 K87-M11BB-000 SCREW,FLAT HEAD 4 P2.6MK-5-IB
24 KW1-M45BF-000 SCREW,FLAT HEAD + 2 3MK-16-P
25 K87-M111S-000 SCREW,FLAT HEAD + 1 3MK-6-P
26 KW1-M459S-000 STRAIGHT PIN 2 4N-9.8A
27
28
29
30
9-10
