8-3
I･pulse F1 Series
F1 - 44 (A type) 44mm
No. Code No. Parts Name Q'ty Parts No.
LG4-M8A10-000
BODY ASSY 1
AS-A44-8101
LG4-M6A1M-000
MAIN LEVER ASSY 1
AS-A24-8145
1
LG4-M1A1L-000
THRUST WASHER 1
CTF- 53- 38-02
2 KW1-M4578-000 STUD 2 CTF- 54- 44
3
KW1-M221F-100
STOPPER PIN 1
CTF-M12- 313
4
K87-M211B-000
BACK STOPPER AXIS 1
CTF-M12- 315
5 LG4-M6A19-000
BACK STOPPER RETURN SP. 1
CTF-55-561
6 KW1-M451H-000 BACK STOPPER 1 FTA-A24-1114
7
LG4-M8A11-000
BODY 1
FTA-A44-8101
8
LG4-M6A12-000
MAIN GUIDE PIN 1
FTA-A24-8102
9
LG4-M1A13-000
LOCATE PIN R 1
FTA-A08-8103-B
10
LG4-M1A14-000
LOCATE PIN F 1
FTA-A08-8104-B
11
LG4-M4A15-000
PLUG HOLDER GUIDE RING 1
FTA-A12-8105
12
LG4-M1A16-000
PLUG HOLDER 1
FTA-A08-8106
13
LG4-M1A1K-000
LEVER AXIS PIN 1
FTA-A08-8130-B
14
LG4-M6A1R-000
STUD 1 FTA-A24-8144
15
LG4-M6A1N-000
MAIN LEVER 1
FTA-A24-8145
16
LG4-M6A1P-000
ARM 1 FTA-A24-8147
17 K87-M56C1-000 BARB CONNECTOR 1
BF4BU
18
LG4-M1AB2-000
PLUG 1
MA-MC05PM
19
LG4-M6ABA-000
AIR HOSE 1
U4B-180
20 K87-M111Y-000 SCREW , SET 1 3MY-4-F
21 K87-M23B3-000 SCREW , SET 2
3MY-5
22 LG4-M1AD1-000 CIRCULAR RIVET 1
φ2-8
23
K87-M1115-000
CIRCULAR RIVET 1
φ2-10
24
LG4-M1AD2-000
CIRCLIP C 1
STW-7
25 K87-M11B9-000 CIRCLIP E 3 E-24
26
27
28
29
30
31
32
8-2
8-3
I･pulse F1 Series
F1 - 44 (A type) 44mm
No. Code No. Parts Name Q'ty Parts No.
LG4-M7A20-000
SPROCKET ASSY 1 AS-A32-8107
LG4-M6A2A-000
RACKING SUB LEVER ASSY 1 AS-A24-8116
1 K87-M532D-000 SCREW COIL SPRING 1
CTF- 42- 11-1
2 K87-M111G-100 PUSH PIN 3
CTF-M08- 325
3 LG4-M6A2F-000 THRUST WASHER 1
CTF-A32- 08
4
LG4-M7A2E-000
LEVER METAL 1 FTA-A32-8108
5 K87-M112G-100 RACKING POLE 1
FTA-A08-1111
6 KW1-M4523-000 SPROCKET 1
FTA-A24-1104
7 KW1-M452W-000 STUD 1 FTA-A24-1118
8 LG4-M7A21-000 METAL 1
FTA-A32-8103
9 LG4-M6A22-000 RACKING MAIN LEVER 1
FTA-A24-8105
10 LG4-M6A25-000 RACKING POLE AXIS 1
FTA-A24-8110
11 LG4-M6A26-000 SPRING HOOK PIN 1 FTA-A24-8111-2
12
LG4-M8A2N-000
RATCHET AXIS 1
FTA-A44-8112
13
LG4-M6A2B-000
RACKING SUB LEVER 1 FTA-A24-8116
14
LG4-M6A2C-000
SHUTTER DRIVE PIN 1
FTA-A24-8116-1
15
LG4-M6A2D-000
MAIN ARM 1
FTA-A24-8117
16 LG4-M7A23-000 SPROCKET 1 FTA-A32-8104
17 LG4-M7A24-000 RATCHET 1
FTA-A32-8107
18 KW1-M552F-000 BEARING 2 MB0808DU
19 K87-M111P-000 SCREW,FLAT HEAD + 9 P2MK-3
20 K87-M111Y-000 SCREW , SET 2 3MY-4-F
21 K87-M23B3-000 SCREW , SET 1 3MY-5
22 K87-M111R-000 SCREW , SET 5 3MY-5-F
23 K87-M55BL-000 U NUT 1 4MH-U
24 K87-M11B9-000 CIRCLIP E 1 E-24
25
26
27
28
29
30
31
32
