I･pulse F1 Series
F1-12 (H type)
P 4
No. Code No. Parts Name Q'ty Parts No.
LG4-M4A40-011
T.G. PLATE ASSY 1 AS-A12-8119-E
LG4-M4A40-012
T.G. PLATE ASSY 1 AS1-A12-8119-E
1
LG4-M4A41-011
TAPE GUIDE PLATE 1
FTA-A12-8119-E
LG4-M4A42-010
SHUTTER PLATE 1
FTA-A12-8120-D
LG4-M4A42-011
SHUTTER PLATE 1
FTA-A12-8120-E
3
LG4-M1A45-000 SHUTTER GUIDE PIN
2
FTA-A08-8121
4
LG4-M1A44-000 SHUTTER PUSH SPRING
1
FTA-A08-8122-B
5
LG4-M4A43-010 SHUTTER GUARD PLATE
1
FTA-A12-8123-C
6
LG4-M1A4L-000 T.G. GUIDE SCREW
1
FTA-A08-8124
7
LG4-M1A47-000 T.G. GUIDE PIN
1
FTA-A08-8125
8
LG4-M1A46-000 LOCK LEVER
1
FTA-A08-8127-B
9
LG4-M1A48-001 T.G. PUSH SPRING
1
FTA-A08-8127-50
10
LG4-M1A4K-000 T.G.A. GUIDE PIN
1
FTA-A08-8129
11
12
13
14
15
16
2
※1
※1
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
※1・・・F1-12-010318H～
I･pulse F1 Series
F１-12 （H type)
P 5
No. Code No. Parts Name Q'ty Parts No.
LG4-M4A60-130 BACK PLATE ASSY 1 AS -A12-8250-E
LG4-M4A60-131 BACK PLATE ASSY 1 AS2-A12-8250-E
LG4-M4A68-000 TENSION LEVER ASSY 1 AS1-A08-8168
1 LG4-M1A72-000 CONNECT PIN
1 FTA-A08-8146
2
LG4-M1A71-000 ROD CONNECT
1 FTA-A08-8147
3
LG4-M1AA3-000 MICRO SWITCH ASSY
1 FTA-A08-8151-6
4
LG4-M1AA4-000 VALVE HARNESS ASSY
1 FTA-A08-8151-7
5
LG4-M1A6K-000 TENSION LEVER
1
FTA-A08-8168
6 LG4-M1A6L-000 COIL SPRING
1
FTA-A08-8168-SP
7
LG4-M1A6E-000
METAL 1 FTA-A08-8169
8 LG4-M4A73-001 ADJUST PLATE
1 FTA-A12-8151-D
9
LG4-M4A6E-010
ADJUST PLATE STUD 2 FTA-A12-8151-1B
10
LG4-M4A6F-000
SET PIN 1 FTA-A12-8152
11
LG4-M4A74-000 PLANE WASHER
2
FTA-A12-8154-B
12
LG4-M4A6J-000
SPRING HOOK PIN 2
FTA-A12-8156
13
LG4-M4A6H-010 ROLLER
2 FTA-A12-8172-1B
14
LG4-M4A6G-010 TAPER ROLLER
1 FTA-A12-8172-2B
15
LG4-M4A69-000 ROLLER AXIS
1
FTA-A12-8172-3
16
LG4-M4A6A-000 ROLLER AXIS T
1 FTA-A12-8173
※1
16
LG4 M4A6A 000
ROLLER
AXIS
T
1
FTA A12 8173
17
LG4-M4A6C-000 LEAF T
1 FTA-A12-8173-1
LG4-M4A6N-010 MIDDLE GUIDE PLATE C
1 FTA-A12-8176-E
LG4-M4A6N-011 MIDDLE GUIDE PLATE C
1 FTA-A12-8176-F
19 LG4-M4A61-130 BACK PLATE 1
FTA-A12-8250-E
20 LG4-M1AB1-010
VAL PACK CYLINDER
1 BDA10×15-380W
21 LG4-M1AB3-000
BARB CONNECTOR
1 BF3BU-136W
22
K87-M111N-000 SCREW,PAN HEAD+
3 3MC-3-P
23
LG4-M1ADC-000 SCREW,PAN HEAD+
1 3MC-7-P
24
LG4-M4ADE-000 SCREW,FLAT HEAD+
1
3MK-7-P
25 LG4-M1ADD-000
SCREW,FLAT HEAD+
1 3MK-14-P
26
LG4-M4ADD-000 SCREW,FLAT HEAD+
3 3MK-15-P
27 K87-MB01H-000 BOLT,HEX SOCKET HEAD 2 3MX-8-P
28 K87-M23B6-000
SCREW,FLAT HEAD+
1 4MK-8-P
29 K87-M23BB-000 BOLT,HEX SOCKET HEAD 2 4MX-10-P
30 K87-M21BM-000 SPRING LOCK WASHER 2
3MU-P
31
LG4-M4AD3-000
SPRING LOCK WASHER 2
4MU-P
32 K87-M11D7-000
CIRCLIP E
1 E.32
33
※1・・・F1-12-008528H～
※2・・・F1-12-009878H～
18※2
