6D-11
I･pulse F1 Series
F1-24 (D type)
P 5
No. Code No. Parts Name Q'ty Parts No.
LG4-M6A80-000
INDENTATION LEV.ASSY 1
AS-A24-8159
LG4-M6A8A-001
SUB LEVER ASSY 1 AS-A24-8160-B
LG4-M6A84-000
REEL SHAFT ASSY 1 AS-A24-8152
LG4-M6A8N-000
METAL ASSY 1 AS2-A24-1153-D
LG4-M6A8F-000
REEL PLATE ASSY 1 AS-A24-1155-E
1 K87-M119J-000 THRUST WASHER 3 CTF- 42- 60-L
2 K87-M111C-000 PLANE WASHER 1 CTF-A08- 16-B
3 KW1-M459P-000 METAL PIN 2 CTF-A12- 653-1
4 K87-M459Y-000 PLANE WASHER 1 CTF-A12- 656
K87-M539M-000 SPRING 1 CTF-A32- 64-2
LG4-M6A89-000
SPRING 1 FTA-A24-8159-68
6 KW1-M459T-000 METAL 1 FTA-A24-1153-D
7 KW1-M459V-000 REEL FLANGE 1 FTA-A24-1154-D
8 KW1-M459U-000 REEL PLATE 1 FTA-A24-1155-E
9
LG4-M6A8E-000
SUB ARM 1 FTA-A24-8146-B
10
LG4-M6A85-000
REEL SHAFT 1 FTA-A24-8152
11
LG4-M6A8D-000
ARM STUD 1 FTA-A24-8158
12
LG4-M6A81-000
INDENTATION LEVER 1 FTA-A24-8159
13
LG4-M6A8B-001
SUB LEVER 1 FTA-A24-8160-B
14
LG4-M6A2C-000 SHUTTER DRIVE PIN
1
FTA-A24-8116-1
15
LG4-M6A8G-000
INDEX GEAR 1 FTA-A24-8161
16
LG4-M6A83-000
DRIVE GEAR 1 FTA-A24-8162
17
LG4-M6A82-000
GEAR AXIS 1 FTA-A24-8163
18 K87-M219E-100 ONE-WAY CRUTCH 1 FC-6
19 KW1-M119B-000 ONE-WAY CRUTCH 1 OWC4-13-3.1-L
20 K87-M5596-000 OILLESS BEARING 1 80B-0808
21
LG4-M6A8R-000
MAGNET 2 φ6-5
22 K87-M11BF-000 SCREW,FLAT HEAD 1 P2MK-4-IB
23 K87-M11BB-000 SCREW,FLAT HEAD 4 P2.6MK-5-IB
24 KW1-M45BF-000 SCREW,FLAT HEAD+ 2 3MK-16-P
25 K87-M111S-000 SCREW,FLAT HEAD+ 1 3MK-6-P
26
KW1-M459S-000 STRAIGHT PIN 2 A4×9.8
27
LG4-M6A8H-000
WARNING LABEL 1 FTA-A24-8151-WL
28
※1．．．F1-24-1371C～
※1
5
6D-10
6D-11
I･pulse F1 Series
F1-24 (D type)
P 6
No. Code No. Parts Name Q'ty Parts No.
LG4-M6A60-010
BACK PLATE ASSY 1 AS1-A24-8150-C
LG4-M6A60-011
BACK PLATE ASSY 1 AS1-A24-8150-D
1 K87-M2387-000 PLANE WASHER 2 CTF- 54- 66-1
2 KW1-M458E-000 RING SCREW 2 CTF-A12- 566-1
3 K87-M538C-000 POSITION PLATE 1 CTF-A32- 49-2
4
LG4-M1A72-000
CONNECT PIN 1 FTA-A08-8146
5
LG4-M6A63-010
ROLLER SHAFT 1 FTA-A24-8132-C
6
LG4-M6A64-000
SHAFT 1 FTA-A24-8140
7
LG4-M6A71-000
ROD CONNECTER 1 FTA-A24-8142
8 LG4-M6A73-001
ADJUST PLATE 1 FTA-A24-8148-C
9
LG4-M6A74-000
CYLINDER BRACKET 1 FTA-A24-8149-B
LG4-M6A61-010
BACK PLATE 1 FTA-A24-8150-C
LG4-M6A61-011
BACK PLATE 1 FTA-A24-8150-D
11
LG4-M6A62-010
REEL SHAFT 1 FTA-A24-8151-B
12
LG4-M6AB1-000
VAL PACK CYLINDER 1 FTA-A24-8157
LG4-M6A6A-000
GUIDE PLATE 1 FTA-A24-8177-B
LG4-M6A6A-010
GUIDE PLATE 1 FTA-A24-8177-C
14 K87-M56C1-000
BARB CONNECTOR
1 BF4BU
15
K87-M111N-000
SCREW,PAN HEAD+ 2 3MC-3-P
16 K87-M111S-000 SCREW,FLAT HEAD+ 2 3MK-6-P
※1 17
LG4-M4ADE-000
SCREW,FLAT HEAD+ 1 2 3MK-7-P
18 K87-M55BN-000 SCREW,FLAT HEAD+ 1 3MK-8-P
19 K87-M11B4-100 SCREW,FLAT HEAD+ 5 3MK-12-P
20 LG4-M6ADJ-000 SCREW,FLAT HEAD LEFT 1 4MK-8-P-L
21 LG4-M6ADE-000 SCREW,FLAT HEAD+ 2 4MK-10-P
※1 22 KW1-M111T-000 SCREW,THIN HEAD 1 TH-TP-HS-M3-5
23 K87-M21BN-000 SCREW NUT 1 3MH-P
24 K87-M11D7-000
CIRCLIP E
1 E.32
25 KW1-M458F-000 DOUBLE RING 2 コクヨ リン-17
26
27
28
29
30
※1．．．F1-24-1611C～
※2．．．F1-24-1711D～
※2
※1
13
10
※2
